Contec Americas GP-IB(PCI)F High performance IEEE488.2/GPIB board for PCI

"This product is a PCI bus compatible interface board with support for bus master operation and which complies with IEEE-488.1 and IEEE-488.2.  The card can be used in a PC to control communications with devices that support the GPIB interface and perform GPIB bus line data analysis.  With the Windows version, the LabVIEW version driver (API-PAC(W32)). "

[Features]

• "As the card complies with the IEEE-488.2 standard, you can control any external device that supports this standard.  The maximum data transfer speed for communications is 1.5Mbyte/sec.  "
• The bus master data transfer function enables large quantities of data to be transferred between the board and PC without loading the CPU.
• "The board has separate 2Kbyte FIFO buffers for sending and receiving data, allowing both small and large volumes of data to be transferred at high speed.  Interface messages also use a FIFO to enable high-speed transmission.  "
• "The board features a bus analyzer function.  This not only allows the signals on the GPIB bus to analyzed, but also permits signal analysis to be performed while the board is performing GPIB communications. "
• "In addition to the functions of the earlier GPIB controller (µPD7210), the board also supports the SPAS event generated when a serial poll occurs.  This gives you a high level of flexibility in constructing your system. "
• The board includes a high-precision application timer to allow accurate time monitoring to be performed under Windows.

[Environmental correspondence] Environmental correspondence  :  Lead-Free
