TRENDnet TI-E100 Industrial Gigabit PoE+ Extend

TRENDnet's Industrial Gigabit PoE+ Extender, model TI-E100, takes a single PoE+ connection and extends it an additional 100m (328 ft.) for remote PoE/PoE+ device installation. The industrial PoE+ extender auto-detects a PoE or PoE+ connection, and then extends it for a total distance of up to 200m (656 ft.) from the PoE+ power source equipment. The TI-E100 industrial PoE+ extender features a convenient wall mountable design for installation fexibility. Daisy-chain up to two industrial PoE+ extenders for a total PoE+ network extension of 300m (984 ft.).

• DEVICE INTERFACE: 1 x Gigabit PoE+ in port; 1 x Gigabit PoE+ out port; LED indicators; DIN-Rail mount; Wall mount ;Grounding point
• NDAA + TAA COMPLIANT: With our NDAA and TAA compliant Industrial Gigabit PoE+ Extender, you can plan and install networking solutions that Government customers demand today (U.S. and Canada Only)
• MANUFACTURER PROTECTION: We stand by the quality of our products.The TI-E100, Industrial Gigabit PoE+ Extender is backed and supported with 3 years of TRENDnet Manufacturer Protection.
• PoE POWERED:Extends a single PoE/PoE+ network connection up to an additional 100m (328 ft.) for a remote PoE or PoE+ device installation. No external power required-saves on cost installation time
• DAISY-CHAINABLE: Daisy-chain up to two industrial PoE+ extenders for a total PoE+ network extension of 300m (984 ft.).
• INDUSTRIAL GRADE DESIGN: Built for harsh environments, with an IP30 enclosure rating, and a wide operating temperature range of -40°- 75° C (-40° - 167° F).

• PoE/PoE+: Auto-sensing technology conveniently delivers the correct wattage needed to power your PoE (15.4W) or PoE+ (30W) device
• LED INDICATORS: LED indicators to convey status
• EXTENSION DISTANCE: Extends a PoE/PoE+ network connection an additional 100m for a total distance of up to 200m (656 ft.) from the PoE power source equipment

More from the Manufacturer

General Information
Manufacturer	TRENDnet
Manufacturer Part Number	TI-E100
Manufacturer Website Address	http://www.trendnet.com
Brand Name	TRENDnet
Product Model	TI-E100
Product Name	Industrial Gigabit PoE+ Extender
Product Condition	New
Product Type	Network Extender
Technical Information
Maximum Extended Range	984.25 ft
Maximum Data Transfer Rate	250 MB/s
Interfaces/Ports
Network (RJ-45)	Yes
Number of Network (RJ-45) Ports	2
Physical Characteristics
Height	4.1"
Width	3.1"
Depth	1.3"
Miscellaneous
Package Contents	Industrial Gigabit PoE+ Extender Quick Installation Guide DIN-Rail And Wall Mount Kit
Additional Information	Standards IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3ab IEEE 802.3af IEEE 802.3at Device Interface 1 x Gigabit PoE+ in port 1 x Gigabit PoE+ out port LED indicators DIN-Rail mount Wall mount Grounding point Data Transfer Rate Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) Gigabit: 2000Mbps (full duplex) Performance Data RAM Buffer: 128KB MAC Address Table: 2K Jumbo Frame: 9KB Special Features Extends a PoE/PoE+ network connection an additional 100 meters Cascade up to 2 units for a total distance of up to 300m (984 ft.) @50V power input Cascade up to 3 units for a total distance of up to 400m (1312 ft.) @56V power input ESD Contact 6kV/Air 8kV and Surge 2kV protection PoE Power input: 15.4W/30W/60W Power output: 15.4W/30W Max. consumption: 3.5W (no PoE) Housing IP30 metal case DIN-Rail mount Wall mount Grounding point Contact 6kV, Air 8kV ESD protection 2kV surge protection Operating Temperature - 40° - 75° C (-40° - 167° F) Operating Humidity Max. 90% non-condensing
Certifications & Standards	CE FCC IEC EN60950-1 Shock (IEC 60068-2-27) Freefall (IEC 60068-2-32) Vibration (IEC 60068-2-6)
Country of Origin	Taiwan
TAA Compliant	Yes
NDAA Compliant	Yes
Warranty
Limited Warranty	3 Year
