STARTECH PEX8S1050LP 8PT PCI EXPRESS SER CARD LP PCIE SER

Add eight RS-232 DB9 serial ports to your desktop computer, through two PCIe expansion card slots. This PCI express serial card, with two breakout cables, provides you with multiple ports to connect a wide variety of serial peripherals, at speeds of up to 921.4Kbps. Connect your Peripherals with 8 Serial Ports The PCI express serial port card makes it easy to add serial ports to connect your peripherals including printers, scanners, credit/debit card readers, PIN pads and modems, industrial controls and more. The 8 port PCIe serial card includes 2 breakout cables - each with 4 DB9 connectors. Versatile Use The low profile PCIe serial card is the ideal choice for adding serial ports, even when space is at a premium. The DB9 serial card is designed to fit into small form factor and standard computer cases. The card comes pre-configured with a low-profile bracket, and includes two optional full-profile brackets, so installation is easy regardless of the case form factor. Windows Only This PCI Express card is only compatible with Windows and Windows server.

More from the Manufacturer

General Information
Manufacturer	StarTech.com
Manufacturer Part Number	PEX8S1050LP
Manufacturer Website Address	http://www.startech.com
Brand Name	StarTech.com
Product Name	8-Port PCI Express Serial Card with 16C1050 UART
Packaged Quantity	1 Each
Product Type	Multiport Serial Adapter
Technical Information
Host Interface	PCI Express x1
Maximum Data Transfer Rate	921.40 kbit/s
Platform Supported	PC
Platform Supported	Linux
Interfaces/Ports
Number of Serial Ports	8
Ports Expandability	8 x DB-9 - Serial, Via Cable
Physical Characteristics
Color Family	Yellow
Product Color	Yellow
Form Factor	Plug-in Card
Height	2.4"
Width	0.9"
Weight (Approximate)	4.09 oz
Miscellaneous
Package Contents	8-Port PCI Express Serial Card with 16C1050 UART 2 x DB44 to 4-Port SB9 Breakout Cables 2 x Full Profile Brackets 1 x Quick-Start Guide
Country of Origin	Taiwan
TAA Compliant	Yes
Environmentally Friendly	Yes
Environmental Certification	EU RoHS
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Environmental Compliance	Restriction of Hazardous Substances (RoHS) 2
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)
End of Life Manual Availability	Yes
EU RoHS Declaration URL	https://media.startech.com/cms/pdfs/pex8s1050lp_rohs.pdf
REACH Declaration URL	https://media.startech.com/cms/pdfs/pex8s1050lp_rohs.pdf
REACH free of SVHC	Yes
WEEE Statement	https://media.startech.com/cms/pdfs/pex8s1050lp_weee.pdf
Warranty
Limited Warranty	Lifetime
