VERTIV PSI5-1500MT120 PSI5 TWR 1440VA 1350W
Mfg Part Number: PSI5-1500MT120 , Item #: 3668770
, PO and Wire.
The Vertiv Liebert PSI5 uninterruptible power supply (UPS) is designed to protect and extend the life of your electronic devices in school, home and office. This 1440VA UPS tower offers cost-effective protection from downtime and damage caused by power outages, brownouts, sags, surges or noise interference. Automatic Voltage Regulation (AVR) extends battery life and safeguards critical equipment. Voltage regulation is from 83 to 159 VAC without using the battery. With advanced pure sine wave output, this line interactive UPS ensures availability of critical IT applications like network closets and small data centers. This battery backup allows orderly shutdown of critical equipment. It takes less than 6 milliseconds transfer time to battery. Add an optional Vertiv Liebert Unity communication card and remotely monitor up to 50 UPS systems with free Vertiv Trellis Power Insight Application. It has a 2-year Vertiv UPS warranty with optional extensions for up to 5 years total coverage.
| General Information | |
| Manufacturer | Vertiv |
| Manufacturer Part Number | PSI5-1500MT120 |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Brand Name | Vertiv Liebert |
| Product Series | PSI5 |
| Product Model | PSI |
| Product Name | PSI5-1500MT120 UPS |
| Product Type | Line-interactive UPS |
| Technical Information | |
| AVR | Yes |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 5 x NEMA 5-15R |
| Dataline Protection | RJ-45 |
| Dataline Protection | RJ-11 |
| Transfer Time | 4 ms |
| Phase | Single Phase |
| Application/Usage | Office |
| Application/Usage | Education |
| Application/Usage | Network Closet |
| Application/Usage | Electronic Device |
| Application/Usage | Mission Critical Equipment |
| Application/Usage | Data Center |
| Application/Usage | Home |
| Power Description | |
| Load Capacity (VA) | 1500 VA |
| Load Capacity (Watt) | 1350 W |
| Input Voltage | 120 V AC |
| Input Voltage Range | 75 V AC - 146 V AC |
| Output Voltage | 120 V AC |
| Output Voltage | 100 V AC |
| Output Voltage | 110 V AC |
| Output Voltage | 125 V AC |
| Output Voltage | 115 V AC |
| Input Frequency | 65 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Pure Sine Wave |
| Interfaces/Ports | |
| Serial Port | No |
| Network (RJ-45) | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information | |
| DC System Voltage | 12 V DC |
| Number of Batteries | 4 |
| Battery Characteristics | Valve-regulated, Non-spillable |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Capacity | 9000 mAh |
| Backup/Run Time (Full Load) | 6 Minute |
| Backup/Run Time (Half Load) | 18 Minute |
| Typical Battery Recharge Time | 8 Hour |
| Hot Swappable | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Storage Temperature | 5°F (-15°C) - 122°F (50°C) |
| Maximum Operating Elevation | 9842.52 ft |
| Operating Humidity | 20% - 90% |
| Storage Relative Humidity | 20% - 90% |
| Physical Characteristics | |
| Height | 8.7" |
| Width | 5.7" |
| Depth | 18.9" |
| Rack Height | 1U |
| Form Factor | Tower |
| Weight (Approximate) | 40.10 lb |
| Miscellaneous | |
| Package Contents |
|
| Software Included | Power Insight 2.2 |
| Energy Star | No |
| Country of Origin | China |
| TAA Compliant | No |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
