CISCO
CISCO UCUCS-EZ-C240M3S UCS C240 M3 SFF DUAL-8C/ 2.7GHZ 128 GB RAM 16X300GB 15
Mfg Part Number: UCUCS-EZ-C240M3S , Item #: 3555043
Special Note: Jan 05, 2020
NCNR; If you do not have loading facility, please contact our CST for special handling service.
, PO and Wire.
The form-factor-agnostic Cisco® Unified Computing System™ (Cisco UCS™) combines Cisco UCS C-Series Rack Servers and B-Series Blade Servers with networking and storage access in a single converged system that simplifies management and delivers greater cost efficiency and agility with increased visibility and control. The latest expansion of the Cisco UCS portfolio includes the new Cisco UCS C240 M3 Rack Server (two rack units [2RU]) and Cisco UCS C220 M3 Rack Server (1RU) and the Cisco UCS B200 M3 Blade Server. These three new servers increase compute density through more cores and cache balanced with more memory capacity and disk drives and faster I/O. Together these server improvements and complementary Cisco UCS advancements deliver the combination of features and cost efficiency required to support IT's diverse server needs.
| General Information | |
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | UCUCS-EZ-C240M3S |
| Manufacturer Website Address | http://www.cisco.com |
| Brand Name | Cisco |
| Product Series | C240 M3 |
| Product Name | UCS C240 M3 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 2 |
| Processor Type | Xeon |
| Processor Model | E5-2680 |
| Processor Core | Octa-core (8 Core) |
| Processor Speed | 2.70 GHz |
| Cache | 20 MB |
| QuickPath Interconnect | 8 GT/s |
| 64-bit Processing | Yes |
| Hyper-Threading | Yes |
| Memory | |
| Standard Memory | 96 GB |
| Maximum Memory Supported | 384 GB |
| Memory Technology | DDR3 SDRAM |
| Memory Standard | DDR3-1600/PC3-12800 |
| Total Number of Memory Slots | 24 |
| Memory Card Reader | Yes |
| Memory Card Supported | SD |
| Storage | |
| Number of Hard Drives | 16 |
| Total Hard Drive Capacity | 4.80 TB |
| Hard Drive Configuration | 16 x 300GB |
| Controllers | |
| Controller Type | Serial Attached SCSI (SAS) |
| Controller Type | Serial ATA |
| I/O Expansions | |
| Total Number of Expansion Slots | 5 |
| Number of PCI Express x8 Slots | 3 |
| Number of PCI Express x16 Slots | 2 |
| Display & Graphics | |
| Graphics Controller Model | G200e |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 5 |
| Number of USB 2.0 Ports | 2 |
| Network (RJ-45) | Yes |
| VGA | Yes |
| Remote Management | Yes |
| Power Description | |
| Input Voltage | 220 V AC |
| Input Voltage | 110 V AC |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 2U |
| Height | 3.4" |
| Width | 17.5" |
| Depth | 28" |
| Miscellaneous | |
| Certifications & Standards | Safety:
EMC: Emissions:
EMC: Immunity:
|
| Warranty | |
| Limited Warranty | 3 Year |
