SAMSUNG
SAMSUNG MZ-V7E500BW 500GB 970 EVO 6G PCIE 2.5IN
Mfg Part Number: MZ-V7E500BW , Item #: 3526036
Image may not reflect the actual item.
Price: $576.94
Quantity:
In Stock: 17
Last Updated: Dec 13, 2025
No Sales Tax except these states
, PO and Wire.
The SSD that goes further
Accelerate into next-gen computing. The Samsung 970 EVO delivers breakthrough speeds, best-in-class reliability, and a broad range of capacity options up to 2TB. The latest V-NAND, new Phoenix controller, and Intelligent TurboWrite technology enhance high-end gaming and 4K & 3D graphic editing.
Next level SSD speed
Feel the NVMe difference. The 970 EVO transforms high-end gaming and streamlines graphic intensive workflows with the new Phoenix controller and Intelligent TurboWrite technology. Get stunning sequential read/write speeds of 3,500/2,500 MB/s, up to 32% faster writes than the previous generation.
Main Specification
| General Information | |
| Manufacturer | Samsung |
| Manufacturer Part Number | MZ-V7E500BW |
| Manufacturer Website Address | http://www.samsung.com/us |
| Brand Name | Samsung |
| Product Series | 970 EVO |
| Product Model | MZ-V7E500BW |
| Product Name | SSD 970 EVO NVMe M.2 500GB |
| Product Type | Solid State Drive |
| Technical Information | |
| Storage Capacity | 500 GB |
| Encryption Standard | 256-bit |
| Drive Performance | |
| Maximum Read Transfer Rate | 3400 MB/s |
| Maximum Write Transfer Rate | 2300 MB/s |
| Endurance (TBW) | 300 TB |
| Network & Communication | |
| Wireless LAN | No |
| Interfaces/Ports | |
| Drive Interface | PCI Express NVMe |
| Drive Interface Standard | PCI Express NVMe 3.0 x4 |
| Power Description | |
| Operating Power Consumption | 10 W |
| Physical Characteristics | |
| Drive Type | Internal |
| Form Factor | M.2 2280 |
| Height | 0.9" |
| Width | 3.2" |
| Depth | 0.1" |
| Weight (Approximate) | 0.28 oz |
| Miscellaneous | |
| Country of Origin | South Korea |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 5 Year |
Specifications
- Mfr Part Number: MZ-V7E500BW
- Capacity: 500GB
- Form Factor: M.2 2280
- Interface: PCIe Gen 3.0 x4, NVMe 1.3
- NAND Flash: Samsung V-NAND 3-bit MLC
- Controller: Samsung Phoenix Controller
- AES Encryption: AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
- Performance: (* Performance may vary based on system hardware & configuration)
- Sequential Read Speed: Up to 3,400 MB/s
- Sequential Write Speed: Up to 2,300 MB/s
- 4K Random Read Speed (QD1): Up to 15K IOPS
- 4K Random Write Speed (QD1): Up to 50K IOPS
- 4K Random Read Speed (QD32): Up to 370K IOPS
- 4K Random Write Speed (QD32): Up to 450K IOPS
- MTBF: 1,500,000 hours
- Power Consumption: (* Actual power consumption may vary depending on system hardware & configuration)
- Average: 5.7W
- Maximum: 10W (Burst mode)
- Idle: 30mW (max)
- Voltage: 3.3 V ± 5 % Allowable voltage
- Shock: 1,500 G & 0.5 ms (Half sine)
- Temperature: 0 ~ 70 °C Operating Temperature
- Dimensions (WxDxH): 3.16 x 0.87 x 0.09 inch
- Weight: 0.28oz. (Max)
