TRIPP LITE
P131-000-A-DISP Tripp Lite HDMI to VGA Active Converter with Audio (F/M), 1920 x 1200 (1080p) @ 60 Hz - Video converter - HDMI - VGA - black
Mfg Part Number: P131-000-A-DISP , Item #: 3503461
, PO and Wire.
Features
Now You Can Watch Video from Your HDMI Computer on a VGA Display
This HDMI to VGA adapter helps you transmit video through your computer's HDMI port to a VGA-enabled television or monitor. It's an ideal tool for giving video presentations in conference rooms and classrooms, editing multiple documents on a larger screen, or streaming video for digital signage in crystal-clear 1080p. It also allows you to keep using your VGA display without the expense of replacing it.
Transmits Crystal-Clear 1080p Video and Stereo Audio
To send high-definition video to a VGA television or monitor, connect the adapter directly to the display's VGA port, and connect an HDMI cable (sold separately) between the adapter's HDMI port and the source device. The adapter supports video resolutions up to 1920 x 1200 (including 1080p) at 60 Hz, as well as HDCP 1.4 and HDMI 1.4b compatibility. Connect the included audio cable between the adapter's audio port and the audio jack on your monitor, A/V receiver or speakers to receive stereo sound.
Ready to Use Right Out of the Package
The molded one-piece unit is so compact that it fits in the palm of your hand, making it easy to carry in your backpack or laptop bag for quick connection anywhere. No software, drivers or external power supply is required. If additional power is needed, use the included USB cable to connect the adapter's USB Micro-B port to a USB charger or a USB-A port on the source device.
| General Information | |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | P131000ADISP |
| Manufacturer Website Address | http://www.eaton.com |
| Brand Name | Tripp Lite series |
| Product Model | P131-000-A-DISP |
| Product Name | HDMI to VGA Active Converter with Audio (F/M), 1920 x 1200 (1080p) @ 60 Hz |
| Product Type | Video Adapter |
| Technical Information | |
| Adapter Type | HDMI/Mini-phone/VGA |
| Connector Type on First End | HD-15 - Male |
| Connector on First End Details | 1 x 15-pin HD-15 VGA Male |
| Connector Type on Second End | HDMI 1.4b Digital Audio/Video - Female |
| Connector Type on Second End | Mini-phone Audio - Female |
| Connector Type on Second End | Micro USB Type B - Female |
| Connector on Second End Details | 1 x Mini-phone Audio Female |
| Connector on Second End Details | 1 x HDMI HDMI 1.4b Digital Audio/Video Female |
| Connector on Second End Details | 1 x Type B Micro USB Female |
| Connector Plating | Nickel |
| Contact Plating | Gold |
| Maximum Resolution Supported | 1920 x 1200 |
| Features | HDCP 1.4 |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Product Material | Acrylonitrile Butadiene Styrene (ABS) |
| Height | 1.3" |
| Width | 2.5" |
| Depth | 0.4" |
| Weight (Approximate) | 1.60 oz |
| Miscellaneous | |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2 |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 3 Year |
