MINUTEMAN EC2000LCD UPS ONLINE 2000/1800W TOWER EXT RUNTIME SNMP OPTIONAL 3YR WARR

On-Line UPS, Comprehensive Protection

Minuteman's Encompass Series delivers the comprehensive protection only offered by a true on-line UPS. By totally regenerating the incoming AC signal through double-conversion technology, an on-line UPS provides an impenetrable "electrical firewall," providing the most fail-safe power protection available.

Designed to protect the most critical equipment used in data centers, voice and data communications, security systems, and light industrial applications. The Encompass Series is SNMP-capable (card optional) and allows full-device management using Minuteman's SentryHD™ power monitoring and control software.

The Encompass product line is a value-priced on-line UPS solution that provides an outstanding set of features, true sinewave output, a three-year warranty (including batteries), and is designed to meet the reliability expectations of even the most demanding critical applications. Two form factors are available in the Encompass Series: a tower-only version (EC-LCD) and a rack/tower version (EC-RT).

General Information
Manufacturer	Para Systems, Inc
Manufacturer Part Number	EC2000LCD
Manufacturer Website Address	http://www.minutemanups.com
Brand Name	Minuteman
Product Line	Encompass
Product Model	EC2000LCD
Product Name	2000 VA On-line Tower UPS with 8 0utlets
Product Type	Double Conversion Online UPS
Technical Information
Plug/Connector Type	NEMA 5-20P
Receptacle Type	NEMA 5-15/20R
Receptacle Detail	8 x NEMA 5-15/20R
Dataline Protection	RJ-11
Dataline Protection	RJ-45
Transfer Time	0 ns
EMI/RFI Noise Filter	Yes
Application/Usage	Education
Application/Usage	Voice/Data Network
Application/Usage	Medical
Application/Usage	Lab Equipment
Application/Usage	Electronic Device
Application/Usage	Network
Application/Usage	Security System
Application/Usage	Healthcare
Application/Usage	Server
Power Description
Load Capacity (VA)	2000 VA
Load Capacity (Watt)	1800 W
Input Voltage	120 V AC
Input Voltage Range	0 V AC - 160 V AC
Output Voltage	110 V AC
Output Voltage	120 V AC
Output Voltage	127 V AC
Input Frequency	60 Hz
Output Frequency	60 Hz
Waveform Type	Pure Sine Wave
Surge Energy Rating	254 J
Management
Network Management	SNMP Manageable
Controls/Indicators
Status Indicators	LCD Status Panel Alarm
Interfaces/Ports
Serial Port	Yes
EPO Port	Yes
USB (HID Compliant) Port	Yes
Battery Information
Number of Batteries	1
Battery Characteristics	Sealed, Non-spillable, Maintenance-free
Battery Chemistry	Lead Acid
Backup/Run Time (Full Load)	3 Minute
Backup/Run Time (Half Load)	10 Minute
Hot Swappable	Yes
Replaceable Battery	Yes
Environmental Conditions
Maximum Operating Temperature	104°F (40°C)
Storage Temperature	14°F (-10°C) - 122°F (50°C)
Maximum Operating Elevation	10000 ft
Maximum Storage Elevation	50000 ft
Operating Humidity	10% - 90%
Storage Relative Humidity	10% - 90%
Sound Emission (A-Weighted)	55 dB(A)
Physical Characteristics
Height	11.4"
Width	6.8"
Depth	17.4"
Form Factor	Tower
Weight (Approximate)	48.10 lb
Miscellaneous
Package Contents	2000 VA On-line Tower UPS with 8 0utlets Batteries Disconnected Quick Installation Guide
Software Included	Minuteman SentryHD Power Monitoring and Control Software
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS) 2
Warranty
Limited Warranty	3 Year
