Perfect Protection For Rack-Mount Systems
The PRO-RT Series is a value-priced, yet feature-rich UPS incorporating line-interactive technology that preserves battery power by providing voltage regulation during brownouts or voltage sags. The PRO-RT Series can be used to support servers, telecom or VoIP systems, security systems, plus many other applications.
The PRO-RT UPSs include many useful features such as load-shedding with two load banks, independent battery bypass, plus auto-re-start when power is restored after an extended power outage.
Versatile Communications
Each PRO-RT model is compatible with Minuteman's free downloadable SentryHD™ power management and diagnostic software. When installed on a workstation or server, the user gains complete control over monitoring and managing the UPS using a convenient web browser-based interface. The SentryHD software communicates via a built-in USB port on the UPS. In addition, managing the UPS within a Network Management System (NMS) is easy with the installation of an optional SNMP card.
Designed for versatility, the PRO-RT models can be mounted in a standard rack using the attached rackmount ears. All units can also be installed as a tower using the included feet. An optional kit is available for mounting the unit to a wall.
High-end Features - Budget Friendly Price
The PRO-RT offers many features normally found on higher priced models, including an LCD status display which shows the following:
- Input / Output voltage and frequency
Monitor the status of your utility power - UPS and battery mode / status
Eliminate guesswork with straightforward display of the unit's status - Load capacity
Load indicator shows how much electrical load is being placed on the unit - Estimated runtime based on connected load
Find out how much backup time remains during a blackout right on the unit
Ideally Suited to Protect:
- Network Equipment
- Servers
- Workstations
- VoIP Communications
- IP and Analog Video Equipment
| General Information | |
| Manufacturer | Para Systems, Inc |
| Manufacturer Part Number | PRO1500RT2U |
| Manufacturer Website Address | http://www.minutemanups.com |
| Brand Name | Minuteman |
| Product Series | PRO-RT |
| Product Model | PRO1500RT2U |
| Product Name | PRO-RT PRO1500RT2U 1500VA Tower/Rack/Wall Mountable UPS |
| Product Type | Line-interactive UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Dataline Protection | RJ-11/RJ-45 |
| Transfer Time | 10 ms |
| Application/Usage | Server |
| Application/Usage | Data Storage |
| Application/Usage | Video Equipment |
| Application/Usage | Telephone System |
| Application/Usage | Security System |
| Application/Usage | Modem |
| Application/Usage | Workstation |
| Application/Usage | Network |
| Application/Usage | VoIP Phone System |
| Application/Usage | Fax Machine |
| Power Description | |
| Load Capacity (VA) | 1500 VA |
| Load Capacity (Watt) | 1050 W |
| Input Voltage | 120 V AC |
| Input Voltage Range | 90 V AC - 150 V AC |
| Output Voltage | 120 V AC |
| Input Frequency | 60 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Simulated Sine Wave |
| Surge Energy Rating | 960 J |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Battery Information | |
| Battery Characteristics | Sealed, Non-spillable, Maintenance-free, Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 4 Minute |
| Hot Swappable | Yes |
| Environmental Conditions | |
| Storage Temperature | 32°F (0°C) - 104°F (40°C) |
| Maximum Operating Elevation | 9842.52 ft |
| Maximum Storage Elevation | 10000 ft |
| Operating Humidity | 5% - 95% |
| Physical Characteristics | |
| Height | 3.4" |
| Width | 18.9" |
| Depth | 20.1" |
| Rack Height | 2U |
| Form Factor | Tower/Rack/Wall Mountable |
| Weight (Approximate) | 48.70 lb |
| Miscellaneous | |
| Certifications & Standards | |
| Energy Star | Yes |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2 |
| Warranty | |
| Limited Warranty | 3 Year |
