"ARCTIC fans are able to cool the system more quietly than the stock fans which aren't even very loud themselves. This was shown in our testing where we recorded a lower noise level for the system with the ARCTIC fans installed. One of the main advantages of these ARCTIC fans over other low-noise alternatives is the impressive price point that they come in at."
Greater Efficiency - Less Noise at Higher Airflow
At low fan speed, the motor noise is key. A motor developed in Germany with a new alloy/lubricant combination reduced friction and noise.
Long Service Life
The Fluid Dynamic Bearing comes with an oil capsule that avoids lubricant leakage. Thus this bearing is as quiet as a sleeve bearing but comes with a significantly higher service life.
Innovative Design Enables Quiet and Efficient Ventilation
The innovative design of the fan blades improves the airflow and facilitates a highly efficient ventilation. The impeller was designed with a focus on minimzing the noise level yet delivering the desired airflow and pressure.
| General Information | |
| Manufacturer | Arctic Cooling |
| Manufacturer Part Number | ACFAN00026A |
| Manufacturer Website Address | http://www.arctic-cooling.com |
| Brand Name | Arctic Cooling |
| Product Line | Silent |
| Product Model | F9 |
| Product Name | 3-Pin Fan with Standard Case |
| Product Type | Cooling Fan |
| Fan Information | |
| Fan Bearing Type | Fluid Dynamic Bearing |
| Fan Speed (Max) | 1000 rpm |
| Maximum Airflow | 21.20 CFM |
| Interfaces/Ports | |
| Connectors | 3-pin |
| Physical Characteristics | |
| Maximum Fan Diameter | 3.62" |
| Fan Height | 3.62" |
| Fan Width | 3.62" |
| Fan Depth | 0.98" |
| Weight (Approximate) | 2.96 oz |
| Miscellaneous | |
| Application/Usage | Case |
