ATEN
ATEN CE620 USB DVI HDBASET2.0 KVM EXTENDER UP TO 330FT W/ 1920X1200
Mfg Part Number: CE620 , Item #: 2807971
Image may not reflect the actual item.
Price: $899.97
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Nov 23, 2025
No Sales Tax except these states
, PO and Wire.
The ATEN CE620 USB DVI HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to provide the most reliable transmission of video, audio, USB and RS-232 signals available on the market. The CE620 delivers high-quality DVI video, PCM 2-channel digital audio, USB 2.0 and RS-232 signals up to 100 meters from the source computer using a single Cat5e/6 cable. With a simple cable installation supporting various signals, the CE620 is ideal for applications where convenient remote access is required - in places such as transportation control centers, medical facilities, industrial warehouses and extended workstations.
Main Specification
| General Information | |
| Manufacturer | ATEN Technology, Inc |
| Manufacturer Part Number | CE620 |
| Manufacturer Website Address | http://www.aten.com/us/en/ |
| Brand Name | ATEN |
| Product Model | CE620 |
| Product Name | USB DVI HDBaseT 2.0 KVM Extender (1920 x 1200@100 m) |
| Product Type | KVM Console/Extender |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Computers Supported | 1 |
| Number of Remote Users Supported | 1 |
| Maximum Operating Distance | 492.13 ft |
| Video | |
| Graphic Mode | WUXGA |
| Maximum Video Resolution | 1920 x 1200 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| USB | Yes |
| DVI | Yes |
| Headphone | Yes |
| Microphone | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of USB Ports | 4 |
| Number of DVI Ports | 2 |
| Power Description | |
| Input Voltage | 5 V DC |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Transmitter Height | 1.13" |
| Transmitter Width | 4.83" |
| Transmitter Depth | 7.17" |
| Receiver Height | 1.13" |
| Receiver Width | 4.83" |
| Receiver Depth | 7.17" |
| Transmitter Weight (Approximate) | 1.39 lb |
| Receiver Weight (Approximate) | 1.41 lb |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 2 Year |
