STARTECH
CAB831HD StarTech.com 8 Port USB PS/2 KVM Switch Modules for 1UCABCONS/17/19
Mfg Part Number: CAB831HD , Item #: 275345
, PO and Wire.
This 8-port KVM module works with the StarTech.com series of rack-mounted LCD consoles, enabling you to control eight servers from one location. You can upgrade a single port LCD console or replace a faulty console (see our list of compatible LCD consoles below).
With independent VGA and PS/2 keyboard and mouse ports, you can also use this switch as a standalone KVM, creating a discreet rack-mountable KVM solution.
Increase your productivity
By adding this KVM module to your rack mountLCD console you can control eight individual computers or servers from a centralized location.
Hassle-free integration
Because the KVM module works with your existing LCD console, you can ensure simple integration into your server room setup. To ensure compatibility this KVM module supports any operating system has been extensively tested in Windows®, Mac and Linux environments.
You can also connect to both PS/2 and USB servers using StarTech.com's convenient line of interface specific KVM cables. The cables come in variety of lengths with PS/2 or USB depending on your specific server requirements.
Compatible LCD consoles
North AmericaRACKCOND1701 (add 8 port module) RACKCONS1908 (replace original module) RACKCONS1916 (replace original module) RACKCONS1708 (replace original module) RACKCONS1716 (replace original module)
United KingdomRACKCOND1701 (add 8 port module) RKCONS1716GB(replace original module) RKCONS1908GB(replace original module)
EuropeRACKCOND1701(add 8 port module) RKCOND1701FR - French Keyboard (add 8 port module)
The CAB831HD is TAA compliant and backed by a 2-year StarTech.com warranty with free lifetime technical support.
More from the Manufacturer
| General Information | |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | CAB831HD |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Line | StarView |
| Product Name | 8 Port PS/2 KVM Switch Module |
| Packaged Quantity | 1 |
| Product Type | KVM Switchbox |
| Technical Information | |
| Number of Computers Supported | 8 |
| Number of Local Users Supported | 1 |
| Minimum Scan Interval | 3 Second |
| Video | |
| Graphic Mode | VGA |
| Maximum Video Resolution | 1920 x 1440 |
| Interfaces/Ports | |
| PS/2 Port | Yes |
| VGA | Yes |
| Number of PS/2 Ports | 2 |
| Number of VGA Ports | 1 |
| Power Description | |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Input Voltage Range | 110V AC to 240V AC |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.7" |
| Width | 17.2" |
| Depth | 7.1" |
| Weight (Approximate) | 4.85 lb |
| Miscellaneous | |
| Package Contents |
|
| Compatibility |
|
| Additional Information |
|
| Platform Supported | Mac |
| Platform Supported | PC |
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
| General Information | |
| Manufacturer | Startech Computer Products |
| Manufacturer Part Number | CAB831HD |
| Manufacturer Website Address | www.startech.com |
| Product Line | StarView |
| Product Name | StarView KVM Switch |
| Marketing Information |
Manage all your computers from one convenient location with a StarTech.com KVM switch. Designed for use with our 1UCABCONS or 1UCABCONS17 TFT panel integrated cabinet consoles, this hybrid KVM allows you to manage 8 USB or PS/2 computers from one console. The CAB831HD uses an intuitive on-screen display and hot-key combinations that let you switch between computers quickly and effectively. Manual and Auto scan modes are provided for easy monitoring of all your systems. The CAB831HD switch fits on your server rack, behind your 1UCABCONS or 1UCABONS17 console and uses rear cable connections for maximum space efficiency. Multiple KVM switches can be cascaded to support up to 64 computers. |
| Product Type | KVM Switch |
| Technical Information | |
| Number of Computers | 8 |
| Number of Users | 1 x Local User |
| Video Signal | VGA |
| Graphics Resolution | 1920 x 1440 |
| Scan Intervals |
|
| Security |
|
| Platform Support |
|
| Interfaces/Ports | |
| User/Console Ports |
|
| Computer Ports | 8 x 15-pin D-Sub (HD-15) Female |
| Other Ports | 1 x 36-pin Centronics Female |
| Power Description | |
| Input Voltage | 9 V DC |
| Input Current | 600mA |
| Physical Characteristics | |
| Form Factor | 1U 19" Rack-mountable |
| Dimensions | 1.7" Height x 17.2" Width x 7.0" Depth |
| Shipping Dimensions | 2" Height x 6.5" Width x 21" Depth |
| Shipping Weight | 5.5 lb Approximate |
| Miscellaneous | |
| Additional Information |
|
| System Requirement |
|
| Compatibility |
|
| Certifications & Standards |
|
| Manufacture Warranty | |
| Standard Warranty | 3 Year(s) |
| Parts Warranty/Labor | 3 Year(s) |
