KRAMER OPS-1 HDBASET RECEIVER COMPATIBLE WITH ALL DEVICES SUPPORTING THE STANDARD OPS SLOT
Mfg Part Number: OPS-1 , Item #: 2352396
Image may not reflect the actual item.
Price: $809.06
+ Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Aug 18, 2025
No Sales Tax except these states
, PO and Wire.
OPS-1 is an OPS-compatible HDBaseT receiver for displays and AV devices with standard Intel OPS-compatible card slots. It is a high-performance, extended-reach HDBaseT 1.0 receiver for full HD HDMI, Ethernet and RS-232 signals over twisted pair. It extends video signals to up to 100m (330ft) over CAT copper cables at up to 1080p@60Hz video resolution.
- High Performance Standard Extender - Professional HDBaseT extender for providing extended-reach signals over twisted-pair copper infrastructures. OPS-1 is a standard extender that can be directly plugged to HDBaseT-compliant OPS-slot of market-available displays and AV products. For optimum extension reach and performance, use recommended Kramer cables.
- HDMI Signal Extension - HDMI 1.4 and HDCP 1.4 compliant. Supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, and 3D. EDID and CEC signals are passed through from the source to the display.
- Multi-channel HDMI Audio Extension - Up to 8 channels of digital stereo uncompressed signals for supporting studio-grade surround sound.
- Ethernet Extension - Ethernet interface data flows in both directions, allowing extension of up to 100Mbps Ethernet connectivity for LAN communication and device control.
- Bidirectional RS-232 Extension - Serial interface data flows in both directions, allowing data transmission and device control.
- Cost-effective Maintenance - Status LED indicator to facilitate easy local maintenance and troubleshooting.
- Easy and Elegant Installation - Directly plugged into OPS-compatible AV devices, drawing power from the device. Provides single cable connectivity for all HDBaseT signals.
- Long-distance AV and LAN signal extension for multi-room, large dividable auditoriums and lecture hall connectivity
Main Specification
| General Information | |
| Manufacturer | Kramer Electronics LTD |
| Manufacturer Part Number | OPS-1 |
| Manufacturer Website Address | http://www.kramerelectronics.com |
| Brand Name | Kramer |
| Product Model | OPS-1 |
| Product Name | OPS-Compatible HDMI Receiver with Ethernet & RS-232 over Extended-Reach HDBaseT |
| Product Type | Video Extender Receiver |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Output Devices Supported | 1 |
| Maximum Operating Distance | 590.55 ft |
| Video | |
| Graphics Modes | Full HD |
| Maximum Video Resolution | 1920 x 1080 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| HDMI Out | Yes |
| Serial Port | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of HDMI Outputs | 1 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Physical Characteristics | |
| Receiver Height | 1.18" |
| Receiver Width | 7.09" |
| Receiver Depth | 4.69" |
| Receiver Weight (Approximate) | 10.58 oz |
| Warranty | |
| Limited Warranty | 7 Year |
