CLUB 3D
CSV-3104D THE CLUB 3D MINI DOCKING STATION ALLOWS YOU TO EXPAND THE OUTPUTS OF YOUR LAPTOP
Mfg Part Number: CSV-3104D , Item #: 2344586
, PO and Wire.
The Club 3D CSV-3104D USB 3.2 Gen 1 4K UHD at 30Hz Mini Docking Station Ultra slim design allows you to expand the outputs of your laptop or ultrabook so it can be used as a traditional desktop PC.
With the advanced DisplayLink™ DL-5900 chip inside, Club3D's USB 3.2
Gen 1 4K UHD at 30Hz Mini Docking Station is able to offer you the perfect solution to connect all your favorite USB devices, as well as connect two external monitors via HDMI™ and a DVI-D Connector, in addition to an Ethernet network Connection it also offers an Audio/Microphone output all via a single USB cable.
Because of its convenient and compact design, the Club 3D USB 3.2 Gen 1 4K UHD at 30Hz Mini Docking Station is a versatile tool that provides you maximum functionality from your Small desktop replacement or mobile companion.
Design:
The Club3D USB 3.2 Gen 1 4K UHD 30Hz Mini Docking Station has a modern and minimalistic design and combines the functionality normally found in larger Docking Stations with a convenient, solid and highly portable casing. The miniature size makes it easy to take it with you wherever you go. Use it without external power for maximum mobility.
| General Information | |
| Manufacturer | Club 3D |
| Manufacturer Part Number | CSV-3104D |
| Manufacturer Website Address | http://www.club-3d.nl |
| Brand Name | Club 3D |
| Product Name | USB 3.2 Gen 1 4K UHD at 30Hz Mini Docking Station |
| Product Type | Docking Station |
| Technical Information | |
| Connectivity Technology | Wired |
| Device Supported | Notebook/Monitor |
| Number of Displays Supported | 2 |
| Screen Mode Supported | 4K |
| Supported Resolutions | 2048 x 1152 |
| Supported Resolutions | 3840 x 2160 |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Host Interface | USB 3.0 |
| Network (RJ-45) | Yes |
| Number of RJ-45 Ports | 1 |
| Headphone/Microphone Combo Port | Yes |
| Number of HDMI Ports | 1 |
| HDMI | Yes |
| HDMI Version | 1.4 |
| DVI | Yes |
| Software | |
| Operating System Supported | macOS |
| Operating System Supported | Windows |
| Physical Characteristics | |
| Height | 1.73" |
| Width | 3.70" |
| Weight (Approximate) | 10.19 oz |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
