BELDEN
BELDEN 3633 0051000 Multi-Paired Cables 23AWG 4PR SOLID 1000ft SPOOL GREEN
Mfg Part Number: 3633 0051000 , Item #: 2306751
Image may not reflect the actual item.
Price: $1,829.65
Quantity:
More to Come
Last Updated: Jan 09, 2026
No Sales Tax except these states
, PO and Wire.
Main Specification
| General Information | |
| Manufacturer | Belden CDT, Inc |
| Manufacturer Part Number | 36330051000 |
| Manufacturer Website Address | http://www.belden.com |
| Brand Name | Belden |
| Product Name | Category 6+ Premium Cable, 4 Bonded-Pairs, U/UTP, CMP |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Category 6+ |
| Cable Length | 1000 ft |
| Cable Shielding Type | Unshielded Twisted Pair (UTP) |
| Connector Type on First End | Bare Wire |
| Connector Type on Second End | Bare Wire |
| Shielding | No |
| Jacket Type | Plenum |
| Jacket Type | CMP |
| Jacket Type | CL3P-LP |
| Jacket Type | CMP-LP |
| American Wire Gauge | 23 AWG |
| Data Transfer Rate | 1 Gbit/s |
| Number of Pairs | 4 |
| Features | Power Sum Attenuation to Crosstalk Ratio, Far-End (PSACRF) |
| Features | Power Sum Attenuation to Crosstalk Ratio (PSACR) |
| Features | Stranded |
| Features | Power-sum Near End Crosstalk (PSNEXT) |
| Features | Attenuation to Crosstalk Ratio (ACR) |
| Features | Power-sum Equal Level Far-End Crosstalk (PSELFEXT) |
| Features | Minimized Near-End Crosstalk (NEXT) |
| Features | PoE++ |
| Features | PoE+ |
| Features | Bendable |
| Features | PoE |
| Physical Characteristics | |
| Color Family | Green |
| Product Color | Green |
| Insulation Color | White/Blue Stripe and Blue |
| Insulation Color | White/Brown Stripe and Brown |
| Insulation Color | White/Green Stripe & Green |
| Insulation Color | White/Orange Stripe and Orange |
| Product Material | Bare Copper |
| Insulation Material | Fluorinated Ethylene Propylene (FEP) |
| Jacket Material | Flamarrest |
| Jacket Material | Low Smoke Polyvinyl Chloride (LS PVC) |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Material Details | Bare Copper - Conductor |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | China Restriction of Hazardous Substances 2 (China RoHS 2) |
| General Information | |
| Type | Cat 6 |
| Number of Conductors | 8 |
| Number of Pairs | 4 |
| Wire Gauge - AWG | 23 AWG |
| Stranding | Solid |
| Conductor Material | Copper |
| Outside Diameter | 6 mm |
| Jacket Material | Low Smoke Polyvinyl Chloride (LS PVC) |
| Length | 1000 ft |
| Shielding | Unshielded |
WARNING:: The plastic used in cable products can expose you to lead and lead components,
chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
