CISCO UCS-SPL-C240M4L-S1 UCS SP SELECT C240M4L STANDARD1 W/ 2XE52630 V3 8X16GB VIC1227

Storage and I/O-Optimized Cisco UCS C-Series Rack Servers

Delivering Outstanding Performance and Expandability

The Cisco UCS® C240 M4 Rack Server is our newest 2-socket, 2-rack-unit (2RU) rack server. It offers outstanding performance and expandability for a wide range of storage and I/O-intensive infrastructure workloads, from big data to collaboration. The enterprise-class Cisco UCS C240 M4 server extends the capabilities of the Cisco Unified Computing System™ (Cisco UCS) portfolio in a 2RU form factor with the addition of the Intel® Xeon® processor E5-2600 v3 product family, which delivers a superb combination of performance, flexibility, and efficiency.

Product Overview

The enterprise-class Cisco UCS C240 M4 server extends the capabilities of the Cisco UCS portfolio in a 2RU form factor. Based on the Intel® Xeon® processor E5-2600 v3 series, it delivers an outstanding combination of performance, flexibility, and efficiency. In addition, the Cisco UCS C240 M4 offers outstanding levels of internal memory and storage expandability with exceptional performance. It delivers:

? Up to 24 DDR4 DIMMs for improved performance and lower power consumption

? Up to 6 PCI Express (PCIe) 3.0 slots (4 full-height, full-length)

? Up to 24 small form factor (SFF) drives or 12 large form factor (LFF) drives, plus two (optional) internal SATA boot drives

? Support for 12-Gbps SAS drives

? A modular LAN-on-motherboard (mLOM) slot for installing a next-generation Cisco virtual interface card (VIC) or third-party network interface card (NIC) without consuming a PCIe slot

? 2 x 1 Gigabit Ethernet embedded LOM ports

? Supports up to two double-wide NVIDIA graphics processing units (GPUs), providing a graphics-rich experience to more virtual users

? Excellent reliability, availability, and serviceability (RAS) features with tool-free CPU insertion, easy-to-use latching lid, hot-swappable and hot-pluggable components, and redundant Cisco® Flexible Flash (FlexFlash) SD cards.

General Information
Manufacturer	Cisco Systems, Inc
Manufacturer Part Number	UCS-SPL-C240M4L-S1
Manufacturer Website Address	http://www.cisco.com
Brand Name	Cisco
Product Series	C240 M4
Product Name	SmartPlay Select C240M4L-Standard-1
Product Type	Server
Processor
Number of Processors Supported	2
Number of Processors Installed	2
Processor Type	Xeon
Processor Model	E5-2630 v3
Processor Core	Octa-core (8 Core)
Processor Speed	2.40 GHz
Memory
Standard Memory	128 GB
Memory Technology	DDR4 SDRAM
Controllers
Controller Type	12Gb/s SAS
Controller Type	Serial ATA
RAID Supported	Yes
RAID Levels	0, 1, 5, 6, 10, 50, 60
Network & Communication
Ethernet Technology	Gigabit Ethernet
Power Description
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1400 W
Physical Characteristics
Form Factor	Rack
Rack Height	2U
Warranty
Limited Warranty	3 Year
