70001208 Digi 8em-PCI DB-25 Multiport Serial Adapter

The AccelePort® 8em asynchronous concentrator is an expandable, modular and intelligent serial communication adapter designed specifically for small to mid-size installations. The Digi AccelePort 8em is optimized for configuring high performance multiuser systems and broad-based server solutions for remote access environments.

General Information
Manufacturer	Digi International
Manufacturer Part Number	70001208
Manufacturer Website Address	http://www.digi.com
Brand Name	Digi
Product Name	8em-PCI DB-25 Multiport Serial Adapter
Product Type	Multiport Serial Adapter
Technical Information
Host Interface	PCI
Maximum Data Transfer Rate	921.60 kbit/s
Protocols	EIA-232
Control Signals	DTR
Control Signals	RTS
Control Signals	DSR
Control Signals	CTS
Control Signals	DCD
Interfaces/Ports
Ports Expandability	8 x DB-25 - Serial
Physical Characteristics
Form Factor	Plug-in Card
Miscellaneous
Additional Information	High-speed dial-in/dial-out remote I/O connections for high-performance remote access systems AccelePort Xem Host Adapter: - PCI host expansion slot - On-board IDT 3051 RISC processor with its patented Front End Processor/Operating System (FEP/OS) - Female HD44 connector to connect the first Digi PORTS Module via a 5-foot (1.5 m) cable Digi PORTS Modules: - Jumper-free installation - EBI technology uses HD44 female connectors on the PORTS Modules to daisy-chain additional ports via a 16-inch (40.6 cm) cable - Auxiliary power supply is required when using two or more PORTS Modules - Can also connect to other Digi EBI products including EPC/CON Concentrators, PortServer II, and MODEM/Xem Environmental requirements: - Air movement: 30 CFM forced
Compatibility	SOFTWARE COMPATIBILITY: - AIX - Digital OpenVMS - Digital UNIX - HP-UX - Linux - Microsoft Windows 95 and 98, Windows NT * - Novell NetWare* - OS/2 - QNX - SCO OpenServer* - SCO UnixWare* - Sun Solaris SPARC - Sun Solaris x86 - UNIX SVR4 *Drivers ship with product on CD-ROM.
Warranty
Limited Warranty	5 Year
Additional Warranty Information	30-day money-back guarantee

The AccelePort Xem asynchronous system is an expandable, modular and intelligent serial communication solution designed specifically for small to mid-size multiuser installations. This product is especially well-suited for applications that are expected to start small and grow over time to as many as 64 ports. This flexible system enables you to connect up to 64 RS-232 or RS-422 serial ports to a Universal PCI (3.3v & 5v) or ISA-based computer. The result is a fast, reliable way to connect terminals, printers, modems, instruments and other serial peripheral devices, making it ideal for applications such as data acquisition, office/factory automation and industrial process control. The AccelePort Xem system features a host adapter card with an on-board RISC-based processor that delivers up to 115.2 Kbps performance per port. The system also includes a compact Digi PORTS module that provides access to eight or 16 serial ports. PORTS modules can also be Ethernet-enabled using the PortServer II. The AccelePort Xem has driver support for a wide array of popular operating systems. It features the same quality, reliability and after-sales technical support that has made Digi the leader in serial connectivity.

Device Type	Serial adapter - 8 ports
Form Factor	Plug-in card
Interface (Bus) Type	PCI
PCI Specification Revision	PCI 2.3
Bus Voltage	Universal (3.3 V & 5.0 V)
Networking
Connectivity Technology	Wired
Data Link Protocol	RS-232
Data Transfer Rate	115.2 Kbps
Processor / Memory
Processor	1 x 3051 - IDT
Expansion / Connectivity
Interfaces	8 x serial - RS-232 - 25 pin D-Sub (DB-25)
Compatible Slots	1 x PCI - full-length
Miscellaneous
Cables Included	1 x serial cable ( external ) - 5 ft
Compliant Standards	FCC Class B certified, CSA
Package Type	Retail
Software / System Requirements
Software Included	Drivers & Utilities
OS Required	IBM OS/2, SCO OpenServer, UnixWare, IBM AIX, Microsoft Windows 95/98, SunSoft Solaris, Compaq Tru64 UNIX, DEC OpenVMS, HP-UX, SunSoft Solaris x86, Novell NetWare, Linux, QNX, Microsoft Windows 2000 / NT4.0, Microsoft Windows Millennium Edition, Microsoft Windows XP
Manufacturer Warranty
Service & Support	5 years warranty
Service & Support Details	Limited warranty - replacement - 5 years - carry-in Limited warranty - money back guarantee - 30 days - carry-in
Environmental Parameters
Min Operating Temperature	50 °F
Max Operating Temperature	131 °F
Humidity Range Operating	5 - 90%
Max Altitude Operating	11810 ft
