COMNET FVR40A4M 4-Channel Digitally Encoded Video Receiver + 4 Audio Channels, mm, 1 fiber
Mfg Part Number: FVR40A4M , Item #: 1772210
, PO and Wire.
The ComNet™ FVT/FVR40A4 series video/audio multiplexer utilizes 10-bit video encoding for true EIA/TIA RS-250C Short-Haul broadcast quality transmission, and 24-bit encoding at a 96 Khz sampling rate for the highest possible audio fidelity. Digitally encoded transmission ensures that the video and audio performance remain completely unaffected up to the maximum usable optical transmission distance or optical path loss. These environmentally hardened units provide the transmission of four independent simplex video and four independent simplex line-level audio channels over one multimode or single mode optical fiber. The FVT/FVR40A4 series is completely transparent to and universally compatible with any NTSC, PAL, or SECAM camera system. Plug-and-play design ensures ease of installation, and no electrical or optical adjustments are ever required.
| General Information | |
| Manufacturer | ACRE |
| Manufacturer Part Number | FVR40A4M |
| Manufacturer Website Address | http://www.acre-co.com |
| Brand Name | ComNet |
| Product Series | FVT/FVR40A4(M,S)1 |
| Product Model | FVR40A4M |
| Product Name | FVR40A4M Video Extender Receiver |
| Product Type | Video Extender Receiver |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Input Devices Supported | 4 |
| Maximum Operating Distance | 6561.68 ft |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Coaxial |
| Power Description | |
| Frequency | 60 Hz |
| Frequency | 50 Hz |
| Physical Characteristics | |
| Receiver Height | 2.20" |
| Receiver Width | 5.30" |
| Receiver Depth | 6.10" |
| Form Factor | Standalone |
| Form Factor | Rack-mountable |
| Form Factor | Rail-mountable |
| Miscellaneous | |
| Package Contents |
|
| Application/Usage | TV |
| Application/Usage | CCTV System |
| Application/Usage | Surveillance System |
| Application/Usage | Audio |
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
