BLACK BOX
BLACK BOX KV9516A 16PORT USB DVI SERVSWITCH EC .
Mfg Part Number: KV9516A , Item #: 1680626
Image may not reflect the actual item.
Price: $1,544.90
+ Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Nov 28, 2025
No Sales Tax except these states
, PO and Wire.
Description
Quick Facts
Further Details
ServSwitch EC for DVI + USB Servers and DVI + USB Console, 16-Port
Quick Facts
- Manage up to 16 servers with this simple plug-and-play KVM switch.
- Resolutions up to 1920 x 1200.
- Perfect for small server rooms.
- 16-port DVI (single link) and USB KVM switch with USB/DVI console.
Further Details
- Unit is 2U high.
- Supports Microsoft® IntelliMouse® (Pro).
- Operating system independent and transparent to all applications.
- Switch with hotkeys, manually, or use autoscan, which selects servers sequentially.
- Hot-pluggable keyboard/mouse ports.
- Plug-and-play configuration.
- DDC2B compatible.
Main Specification
| General Information | |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | KV9516A |
| Manufacturer Website Address | http://www.blackbox.com |
| Brand Name | Black Box |
| Product Line | ServSwitch |
| Product Name | ServSwitch EC for DVI + USB Servers and DVI + USB Console, 16-Port |
| Packaged Quantity | 1 |
| Product Type | KVM Switchbox |
| Technical Information | |
| Number of Computers Supported | 16 |
| Number of Local Users Supported | 1 |
| Minimum Scan Interval | 3 Second |
| Video | |
| Graphic Mode | WUXGA |
| Maximum Video Resolution | 1920 x 1200 |
| Interfaces/Ports | |
| USB | Yes |
| DVI | Yes |
| Number of USB Ports | 18 |
| Number of DVI Ports | 17 |
| Power Description | |
| Input Voltage | 12 V DC |
| Input Voltage | 110 V AC |
| Input Voltage | 220 V AC |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 2.6" |
| Width | 17.3" |
| Depth | 9" |
| Weight (Approximate) | 8.40 lb |
| Miscellaneous | |
| Package Contents |
|
| Platform Supported | PC |
| Platform Supported | Mac |
| Certifications & Standards | CE |
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 1 Year |
Connector Cables
