This Converter allows you to convert a composite BNC video signal to a VGA signal, thus allowing you to use a standard VGA/SVGA monitor with devices that have BNC video outputs. For example, surveillance DVRs, security cameras and quad video processors can be displayed on your VGA/SVGA monitor. It is compact in size with easy plug and play installation.
General Information | |
Manufacturer | Bytecc, Inc |
Manufacturer Part Number | HM104 |
Manufacturer Website Address | http://www.byteccusa.com |
Brand Name | Bytecc |
Product Model | HM104 |
Product Name | HM104 BNC Composite and S-Video to VGA Converter (Wide screen) |
Packaged Quantity | 1 |
Product Type | Signal Converter |
Technical Information | |
Functions | Signal Conversion |
Functions | Video Conversion |
Functions | Video Processing |
Video Signal Format | PAL |
Video Signal Format | NTSC |
Maximum Resolution | 1680 x 1050 |
Interfaces/Ports | |
VGA | Yes |
S-Video | Yes |
Composite Video | Yes |
Physical Characteristics | |
Form Factor | External |
Height | 1" |
Width | 3.9" |
Depth | 2.4" |
