TRIPP LITE
N820-05M-OM4 Tripp Lite 10Gb/100Gb Duplex Multimode 50/125 OM4
Mfg Part Number: N820-05M-OM4 , Item #: 1252422
, PO and Wire.
Tripp Lite introduces it's new OM4 Laser-Optimized Multimode Fiber (LOMMF) "Aqua" cables, for use with 40/100Gb Ethernet applications. These new technology, 50/125um, LC/LC Fiber Optic cables, provide nearly three times the bandwidth over conventional 62.5um multimode fiber, with performance rivaling that of Singlemode cable, at a much reduced cost. LOMMF cable allows 40/100Gb serial transmission over extended distances in the 850nm wavelength window, where low-cost Vertical Cavity Surface Emitting Lasers (VCSELs) enable a cost-effective, high-bandwidth solution. LOMMF is ideally suited for LAN's, SAN's, and high-speed parallel interconnects for head-ends, central offices, and data centers. Tripp Lite warrants this product to be free from defects in material and workmanship for Life.
| General Information | |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | N820-05M-OM4 |
| Manufacturer Website Address | https://tripplite.eaton.com/ |
| Brand Name | Tripp Lite series |
| Product Model | N820-05M-OM4 |
| Product Name | N820-05M-OM4 Fiber Optic Duplex Patch Cable |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Fiber Optic |
| Cable Characteristic | Patch Cable |
| Fiber Optic Mode | Multi-mode |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm |
| Cable Length | 16.40 ft |
| Connector Type on First End | LC Network - Male |
| Connector on First End Details | 2 x LC Network - Male |
| Connector Type on Second End | LC Network - Male |
| Connector on Second End Details | 2 x LC Network - Male |
| Jacket Type | LSZH |
| Device Supported | Network Device |
| Physical Characteristics | |
| Color Family | Green |
| Product Color | Aqua |
| Shipping Height | 3.90" |
| Shipping Width | 7.10" |
| Shipping Weight (Approximate) | 1.20 lb |
| Miscellaneous | |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
| General Information | |
| Mode | - |
| Port Type | - |
| Application | - |
| Connector End A | - |
| Connector End B | - |
| Cable Type | - |
| Fiber Diameter | - |
| Length | - |
| Number of Fibers | - |
| Ferrule Material | - |
