| Ethernet Interface | |
| No. of Ports | 1 |
| Speed | 10/100 Mbps, auto MDI/MDIX |
| Connectors | 8-pin RJ45 |
| Magnetic Isolation Protection | 1.5 KV built-in |
| Ethernet Line Protection | Level 2 Surge, EN61000-4-5 |
| Serial Interface | |
| Serial Standards | NPort® 5210A: RS-232 NPort® 5230A: RS-422/485 NPort® 5250A: RS-232/422/485 |
| Number of Ports | 2 |
| Connectors | NPort 5210A/5250A: DB9 male NPort 5230A: Terminal Block (5 pins per port) |
| Serial Line Protection | 15 KV ESD protection for all signals, Level 1 Surge, EN61000-4-5 |
| RS-485 Data Direction Control | ADDC® (automatic data direction control) |
| Pull High/Low Resistor for RS-485 | 1 KΩ, 150 KΩ |
| Serial Communication Parameters | |
| Data Bits | 5, 6, 7, 8 |
| Stop Bits | 1, 1.5, 2 |
| Parity | None, Even, Odd, Space, Mark |
| Flow Control | RTS/CTS and DTR/DSR (RS-232 only), XON/XOFF |
| Baudrate | 50 bps to 921.6 Kbps |
| Serial Signals | |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| RS-422 | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485-4w | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485-2w | Data+, Data-, GND |
| Software | |
| Network Protocols | ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, IGMP V1/2 |
| Configuration Options | Web Console (with new Quick Setup), Serial Console (NPort 5210A/5250A only), Telnet Console, Windows Utility |
| Fixed TTY Drives | SCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac 10.3 |
| Linux Real TTY Drivers | Linux kernel 2.4.x, 2.6.x |
| Windows Real COM Drivers | Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64 |
| Physical Characteristics | |
| Housing | Metal |
| Dimensions | Without ears: 77 x 111 x 26 mm (3.03 x 4.37 x 1.02 in) With ears: 100 x 111 x 26 mm (3.94 x 4.37 x 1.02 in) |
| Environmental Limits | |
| Operating Temperature | Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Operating Humidity | 5 to 95% RH |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Power Requirements | |
| Input Voltage | 12 to 48 VDC |
| Power Consumption | 119 mA @ 12V, 65 mA @ 24V |
| Regulatory Approvals | |
| Safety | UL (UL60950-1), LVD (EN60950-1) |
| EMC | CE (EN55022 Class A, EN55024), FCC Part 15 Subpart B Class A |
| Power Line Protection | Level 2 Burst (EFT), EN61000-4-4, Level 3 Surge, EN61000-4-5 |
| Reliability | |
| Automatic Reboot Trigger | Built-in WDT (watchdog timer) |
| Warranty | |
| Warranty Period | 5 years |
| Mechanical | |
| Dimensions: WxHxD (mm) | 100 x 111 x 26 |
| Mounting | Din Rail Mount; Wall Mount |
| Enclosure | Metal |
| Interface | |
| Serial interface | RS232/RS422/RS485 |
| Serial interface number of ports | 2 |
| Serial Interface type of connector | DB9 |
| Network interface | 1 Port Ethernet RJ45 Connector |
| Network interface number of ports | 1 |
| Network interface type of connector | RJ45 |
| Power | |
| Power Input Type | Single DC / Terminal Block |
| Operating Supply Voltage | 12 to 48 VDC |
| Power Consumption | 119 mA @ 12V |
| Reliability | |
| Operating Temperature | 0 to 60C |
| Isolation Protection | Yes |
| Surge Protection | Yes |
| Standards and Certifications | Safety UL 60950-1, EN 60950-1, EMC CE, FCC, EMI EN 55022 Class A, FCC Part 15 Subpart B Class A, EMS EN 55024 |
| Power Requirements | |
| Power Consumption | 119 mA @ 12V, 65 mA @ 24V |
| Input Voltage | 12 to 48 VDC |
| Software | |
| Linux Real TTY Drivers | Linux kernel 2.4.x, 2.6.x |
| Configuration Options | Web Console (with new Quick Setup), Serial Console (NPort 5210A/5250A only), Telnet Console, Windows Utility |
| Windows Real COM Drivers | Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64 |
| Network Protocols | ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, IGMP V1/2 |
| Fixed TTY Drivers | SCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac 10.3 |
| Serial Communication Parameters | |
| Flow Control | RTS/CTS and DTR/DSR (RS-232 only), XON/XOFF |
| Data Bits | 5, 6, 7, 8 |
| Parity | None, Even, Odd, Space, Mark |
| Stop Bits | 1, 1.5, 2 |
| Baudrate | 50 bps to 921.6 Kbps |
| Ethernet Interface | |
| Connector | 8-pin RJ45 |
| Speed | 10/100 Mbps, auto MDI/MDIX |
| Magnetic Isolation Protection | 1.5 KV built-in |
| Number of Ports | 1 |
| Ethernet Line Protection | EN61000-4-5 (Surge) Level 2 |
| Environmental Limits | |
| Operating Temperature | Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Physical Characteristics | |
| Weight | 340 g |
| Dimensions | Without ears: 77 x 111 x 26 mm (3.03 x 4.37 x 1.02 in) With ears: 100 x 111 x 26 mm (3.94 x 4.37 x 1.02 in) |
| Housing | Metal |
| Serial Interface | |
| Connector | NPort 5210A/5250A: DB9 male NPort 5230A: Terminal Block (5 pins per port) |
| Serial Standards | NPort 5210A: RS-232 NPort 5230A: RS-422/485 NPort 5250A: RS-232/422/485 |
| RS-485 Data Direction Control | ADDC® (automatic data direction control) |
| Number of Ports | 2 |
| Pull High/Low Resistor for RS-485 | 1 KΩ, 150 KΩ |
| Serial Line Protection | 15 KV ESD protection for all signals, EN61000-4-5 (Surge) Level 1 |
| Reliability | |
| MTBF (mean time between failures) | 847,750 hrs |
| Automatic Reboot Trigger | Built-in WDT (watchdog timer) |
| Serial Signals | |
| RS-485-4w | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485-2w | Data+, Data-, GND |
| RS-422 | Tx+, Tx-, Rx+, Rx-, GND |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| Standards and Certifications | |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| Safety | UL 60950-1, EN 60950-1 |
| EMS | EN 55024 |
| EMC | CE, FCC |
| Power Line Protection | EN61000-4-4 (EFT) Level 2, EN61000-4-5 (Surge) Level 3 |
| Warranty | |
| Warranty Period | 5 years |
| Details | See http://www.moxa.com/support/warranty.htm |
