The EDS1100 and EDS2100 are unique, hybrid Ethernet terminal/multiport device servers which allow remote access to and management of virtually any IT/networking equipment or edge device such as medical equipment, POS terminals or security equipment.
Main Specification
| General Information | |
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | ED2100002-LNX-01 |
| Manufacturer Website Address | http://www.lantronix.com |
| Brand Name | Lantronix |
| Product Model | EDS2100 |
| Product Name | EDS2100 Hybrid Ethernet Terminal Device Server |
| Product Type | Device Server |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| Network Standard | 10/100Base-TX |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Serial Port | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of Serial Ports | 2 |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 0.9" |
| Width | 2.8" |
| Depth | 3.7" |
| Weight (Approximate) | 14.11 oz |
| Miscellaneous | |
| Package Contents |
|
| Additional Information | Built in IPv6 |
| Environmentally Friendly | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
| Mechanical | |
| Dimensions: WxHxD (mm) | 95 x 72 x 23 |
| Mounting | Din Rail Mount; Wall Mount |
| Enclosure | Metal |
| Interface | |
| Serial interface | RS232/RS422/RS485 |
| Serial interface number of ports | 2 |
| Serial Interface type of connector | DB9 |
| Network interface | 1 Port Ethernet RJ45 Connector |
| Network interface number of ports | 1 |
| Network interface type of connector | RJ45 |
| Power | |
| Power Input Type | Single AC or DC / Jack |
| Operating Supply Voltage | 9 to 30VDC/9 to 24VDC |
| Power Consumption | 1.8W |
| Reliability | |
| Operating Temperature | -40 to 75C |
| Isolation Protection | - |
| Surge Protection | - |
| Standards and Certifications | Safety UL 60950-1, EN 60950-1, EMC CE, FCC, EMI EN 55022 Class A, FCC Part 15 Subpart B Class A, EMS EN 55024 |
