Moxa EDS-408A-3S-SC-48-T Entry-level Managed Industrial Ethernet Switch with 5 10/100BaseT(X) ports, 3 single mode 100BaseFX ports, SC connector, -48VDC, -40 to 75°C
MOXA Major LinesMfg Part Number: EDS-408A-3S-SC-48-T , Item #: 1148760
Status: Active
, PO and Wire.
Certifications: EN 55032/EN 55024FCC Part 15BLVD(EN 60950-1)RoHSUL508
The EDS-408A are entry-level 8-port managed Ethernet switches designed especially for industrial applications. The switches support a variety of useful management functions, such as Turbo Ring, Turbo Chain, ring coupling, port-based VLAN, QoS, RMON, bandwidth management, port mirroring, and warning by email or relay. The ready-to-use Turbo Ring can be set up easily using the web-based management interface, or with the DIP switches located on the top panel of the EDS-408A switches.
- IPv6 Ready logo awarded (IPv6 Logo Committee certified)
- DHCP Option 82 for IP address assignment with different policies (available soon)
- Modbus/TCP industrial Ethernet protocol supported (available soon)
- IEC 61850 GOOSE messaging compliance
- Plug-n-Play Turbo Ring (recovery time < 20 ms at full load) and RSTP/STP (IEEE 802.1w/D) capability
- Port-based VLAN to ease network planning
- QoS (IEEE 802.1p and TOS/DiffServ) to increase determinism
- RMON for efficient network monitoring and proactive capability
- SNMPv1/v2c/v3 for different levels of network management
- Bandwidth management prevents unpredictable network status
- Port mirroring for online debugging
| Product Category | |
| Product Category | Managed Switch |
| Mechanical | |
| Dimensions: WxHxD (mm) | 53.6mm x 135mm x 105mm |
| Mounting | Din Rail |
| IP level | IP30 |
| Enclosure | Metal |
| Data Rate and Number of Ports | |
| Number of Ports | 8 |
| Fast Ethernet, 10/100 Mbps | 5 |
| Gigabit, 10/100/1000 Mbps | - |
| Interface | |
| Interface Type | 10/100 Mbps RJ45, 100 Mbps Single-mode SC |
| Fiber connector | 3 Single-Mode SC |
| PoE | - |
| M12 Connector | - |
| SFP | |
| Digital I/O/Relay | Yes |
| Console | - |
| Bypass | - |
| Modular Design | - |
| Available Modular | - |
| Power | |
| Power Input Type | Redundant DC/DC Terminal Block |
| Operating Supply Voltage | 48VDC |
| Power Consumption | 0.32 A @ 24V |
| Reliability | |
| Operating Temperature | -40C to 75C |
| Redundancy and Backup Options | |
| Redundancy Technology | Yes |
| STP/RSTP/PSTP/MSTP | Yes |
| Automatic Backup Configurator | Yes |
| Certification | |
| Certification | |
| UL 508 (Industrial Control) | |
| EN 50155 (Rail Industry) | |
| EN 50121-4 (Rail Industry) | |
| EN 50121-3-2 (Rail Industry) | |
| NEMA TS2 (ITS) | |
| IEC 61850-3 (Power Industry) | |
| IEEE 1613 (Power Industry) | |
| IEEE 1588PTP (Power Industry) | |
| DNV.GL (Marine) | |
| ABS.LR.NK (Marine) | |
| C1D2 (Oil & Gas) | |
| ATEX (Oil & Gas) | |
| Network Management and Control | |
| Layer Level Switching | L2 |
| Modbus/TCP | Yes |
| Ethernet/IP | Yes |
| PROFINET | Yes |
| SNMP/RMON | Yes |
| LLDP | Yes |
| DHCP | Yes |
| IGMP Snooping/GMRP | Yes |
| QoS | - |
| VLAN 802.1Q | - |
| IEEE 802.1X | Yes |
| LACP (802.3ad) | |
| Port Lock | - |
| IPv6 | Yes |
Specification
| Interface | |
| Console Port | RS-232 (RJ45 connector) |
| DIP Switches | Turbo Ring, Master, Coupler, Reserve |
| Fiber Ports | 100BaseFX ports (SC/ST connector) |
| LED Indicators | PWR1, PWR2, FAULT, MSTR/HEAD, CPLR/TAIL, 10/100M |
| Alarm Contact | 1 relay output with current carrying capacity of 1 A @ 24 VDC |
| RJ45 Ports | 10/100BaseT(X) auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection |
| Power Requirements | |
| Overload Current Protection | Present |
| Reverse Polarity Protection | Present |
| Input Voltage | ±24/±48 VDC (-60 to -19 VDC or 19 to 60 VDC), redundant dual inputs (mixing power polarity systems is prohibited) |
| Input Current | 0.32 A @ 24 V |
| Inrush Current | 63 A @ 24 V 82 A @ 48 V |
| Connection | 1 removable 6-contact terminal block |
| Technology | |
| Standards | IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3x for Flow Control IEEE 802.1D-2004 for Spanning Tree Protocol* IEEE 802.1w for Rapid STP IEEE 802.1p for Class of Service IEEE 802.1Q for VLAN Tagging |
| Flow Control | IEEE 802.3x flow control, back pressure flow control |
| Protocols | IGMPv1/v2, GMRP, GVRP, SNMPv1/v2c/v3, DHCP Server/Client, TFTP, SNTP, SMTP, RARP, RMON, HTTP, Telnet, Syslog, DHCP Option 66/67/82, BootP, LLDP, Modbus/TCP, IPv6, NTP Server/Client* |
| MIB | MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9 |
| Environmental Limits | |
| Operating Temperature | Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| MTBF (mean time between failures) | |
| Time | 363,000 hrs |
| Database | Telcordia (Bellcore), GB |
| Physical Characteristics | |
| Weight | 890 g |
| Dimensions | 53.6 x 135 x 105 mm (2.11 x 5.31 x 4.13 in) |
| Installation | DIN-Rail mounting, wall mounting (with optional kit) |
| Housing | Metal, IP30 protection |
| Switch Properties | |
| MAC Table Size | 8 K |
| Packet Buffer Size | 1 Mbit |
| Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A, EN 55022 Class A |
| Safety | UL 508 |
| Note | Please check Moxa’s website for the most up-to-date certification status. |
| Shock | IEC 60068-2-27 |
| Vibration | IEC 60068-2-6 |
| EMS | EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3, EN 61000-4-8 |
| Freefall | IEC 60068-2-32 |
| Warranty | |
| Warranty Period | 5 years |
| Details | See www.moxa.com/warranty |
