Image may not reflect the actual item.
Price: $317.00
Quantity:
In Stock: 130
Last Updated: May 02, 2025
No Sales Tax except these states
, PO and Wire.
The EDS1100 and EDS2100 are unique, hybrid Ethernet terminal/multiport device servers which allow remote access to and management of virtually any IT/networking equipment or edge device such as medical equipment, POS terminals or security equipment. The EDS delivers an unprecedented level of intelligence and safety. Available with Linux and IPv6 or Lantronix' powerful Evolution OS, the EDS1100/2100 is the best choice when critical data needs to be remotely and securely accessed anywhere, at any time, via the Internet.
Main Specification
| General Information | |
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | ED1100002-01 |
| Manufacturer Website Address | http://www.lantronix.com |
| Brand Name | Lantronix |
| Product Model | EDS1100 |
| Product Name | EDS1100 1-Port Secure Device Server |
| Product Type | Device Server |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| Network Standard | 10/100Base-TX |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Physical Characteristics | |
| Form Factor | Desktop |
| Height | 0.9" |
| Width | 2.5" |
| Depth | 3.5" |
| Weight (Approximate) | 7.20 oz |
| Miscellaneous | |
| Additional Information |
|
| Environmentally Friendly | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
| Mechanical | |
| Dimensions: WxHxD (mm) | 90 x 64 x 23 |
| Mounting | Din Rail Mount; Wall Mount |
| Enclosure | Metal |
| Interface | |
| Serial interface | RS232/RS422/RS485 |
| Serial interface number of ports | 1 |
| Serial Interface type of connector | DB25 |
| Network interface | 1 Port Ethernet RJ45 Connector |
| Network interface number of ports | 1 |
| Network interface type of connector | RJ45 |
| Power | |
| Power Input Type | Single AC or DC / Jack |
| Operating Supply Voltage | 9 to 30VDC/9 to 24VDC |
| Power Consumption | 1.5W |
| Reliability | |
| Operating Temperature | -40 to 75C |
| Isolation Protection | - |
| Surge Protection | - |
| Standards and Certifications | Safety UL 60950-1, EN 60950-1, EMC CE, FCC, EMI EN 55022 Class A, FCC Part 15 Subpart B Class A, EMS EN 55024 |
Connector Adapters
Connector Cables
Mounting Kits
Similar Products:
LANTRONIX
(ED2100002-01)
Lantronix 2-Port Secure Serial (RS232/ RS422/ RS485) to IP Ethernet Device Server; Up to 256-bit AES encryption; SSH/SSL/TLS Enterprise Security with PKI; International 110-240 VAC
Lantronix 2-Port Secure Serial (RS232/ RS422/ RS485) to IP Ethernet Device Server; Up to 256-bit AES encryption; SSH/SSL/TLS Enterprise Security with PKI; International 110-240 VAC
$450.00
