| Technology: | |
| Standards | IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X), 100BaseFX |
| Interface: | |
| RJ45 Ports | 10/100BaseT(X) |
| Fiber Port(s) | 100BaseFX (SC/ST connectors) |
| LED Indicators | PWR, Fiber Link, 10/100M (TP port) |
| Optical Fiber | |
![]() |
|
| Power Requirements: | |
| Input Voltage | 12 VDC |
| Power Consumption | 180 mA @ 12 VDC |
| DIP Switches | |
![]() |
|
| Physical Characteristics: | |
| Housing | SPCC |
| Dimensions | 86.8 x 124.3 x 21 mm (3.42 x 4.89 x 0.83 in) |
| Environmental Limits: | |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -20 to 75°C (-4 to 158°F) |
| Operating Humidity | 5 to 95% RH |
| Agency Approvals: | |
| FCC | Part 15 sub part B Class A |
| CE | Class A |
| EMS | EN61000-4-2 (ESD), Criteria A, Level 4 EN61000-4-3 (RS), Criteria A, Level 2 EN61000-4-4 (EFT), Criteria A, Level 3 EN61000-4-5 (Surge), Criteria A, Level 3 EN61000-4-6 (CS), Criteria A, Level 2 EN61000-4-8 (PFMF), Criteria A, Level 3 |
| Freefall | IEC 60068-2-32 |
| Warranty: | |
| Warranty Period | 5 years |
| Interface | |
| Fiber Ports | 100BaseFX (SC/ST connectors) |
| LED Indicators | PWR, Fiber Link, 10/100M (TP port) |
| RJ45 Ports | 10/100BaseT(X) |
| Power Requirements | |
| Power Consumption | 180 mA @ 12 VDC |
| Input Voltage | 12 VDC |
| Technology | |
| Standards | IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X), 100BaseFX |
| Environmental Limits | |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -20 to 75°C (-4 to 167°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| MTBF (mean time between failures) | |
| Time | 1,454,560 hrs |
| Database | Telcordia (Bellcore), GB |
| Physical Characteristics | |
| Weight | Product only: CSM-200-1213: 115 g (0.25 lb) CSM-200-1214/1218: 125 g (0.28 lb) Packaged: CSM-200-1213: 170 g (0.37 lb) CSM-200-1214/1218: 180 g (0.40 lb) |
| Dimensions | 86.8 x 124.3 x 21 mm (3.42 x 4.89 x 0.83 in) |
| Housing | SPCC |
| Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A, EN 55022 Class A |
| Safety | UL 60950-1 |
| EMS | EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 2, EN 61000-4-5 (Surge) Level 2, EN 61000-4-6 (CS) Level 2, EN 61000-4-8 (PFMF) Level 3 |
| EMC | CE, FCC |
| Freefall | IEC 60068-2-32 |
| Warranty | |
| Warranty Period | 5 years |
| Details | See http://www.moxa.com/support/warranty.htm |
