ADVANTECH EKI-1524-AE 4-port RS-232/422/485 Serial Device Server

Mfg Part Number:  EKI-1524-AE
Image may not reflect the actual item.
Price: $427.20
Quantity:
In Stock: 1
No Sales Tax except these states
, PO and Wire.
Manufacturer Warranty Policy:
EKI-1524 feature two independent Ethernet ports and MAC addresses to provide a redundant networking mechanism to guarantee Ethernet networking reliability. The EKI-1524 is a network-based, serial device server for connecting four RS-232/422/485 devices, such as CNCs, PLCs, scales, and scanners,directly to a TCP/IP network. Once connected through EKI-1524 device server, your serial device will be able to send and receive data on a network like any other network device. EKI-1524 provide a simple and cost-effective way to bring the advantages of remote management and data accessibility to thousand of devices that can not connect to a network.
EKI-series device server provide various operations: COM port redirection (Virtual COM port), TCP server Client and UDP mode. After Advantech redirection software installation, standard serial operating calls are transparently redirected to the EKI- series device server, guaranteeing compatibility with legacy serial devices and enabling backward compatibility with existing software. EKI-1524 also support serial tunneling, allowing two native serial devices to communicate over a network.
  • Provides 2 x 10/100 Mbps Ethernet ports for LAN redundancy
  • Provides COM port redirection (Virtual COM), TCP and UDP operation modes
  • Supports baud rate up to 921.6 kbps
  • Allows a max. of 5 hosts to access one serial port
  • Allows a max. of 16 hosts to be accessed as TCP client mode
  • Built-in 15 KV ESD protection for all serial signals
  • Provides rich configuration methods including Windows utility, Telnet console, and Web Browser
  • Supports Windows 2000/XP/Vista drivers
  • Automatic RS-485 data flow control
  • SNMP MIB-II for network management
Connector Ethernet RJ45
Serial DB9
Ethernet Interface 10/100 Mbps
Ports 2
Serial Ports 4
Type RS-232/422/485
Software Baud Rate 50 ~ 921.6 Kbps
Driver Windows 2000/XP/Vista
Operating Mode Virtual COM, Data Mode, Control Mode
Mechanical
Dimensions: WxHxD (mm) 48 x 140 x 95
Mounting Din Rail Mount; Wall Mount
Enclosure Metal
Interface
Serial interface RS232/RS422/RS485
Serial interface number of ports 4
Serial Interface type of connector DB9
Network interface 2 Port Ethernet RJ45 Connector
Network interface number of ports 2
Network interface type of connector RJ45
Power
Power Input Type Dual DC/DC / Terminal Block
Operating Supply Voltage 12 to 48 VDC
Power Consumption 6.3W
Reliability
Operating Temperature -10 to 60C
Isolation Protection Yes
Surge Protection -
Standards and Certifications EMC CE, FCC Part 15 Subpart B (Class A)
