Cisco 880 Series Integrated Services Routers are the next generation of fixed-configuration routers that provide collaborative business solutions for secure data communication to small businesses and enterprise teleworkers. The embedded 3G wireless on these routers offers a cost-effective, rapidly deployable, reliable, and secure backup solution. With data rates exceeding T1 speeds, 3G wireless can be used for primary WAN connectivity in locations where wire-line services such as DSL and ISDN are not available or are too expensive to deploy.
General Information | |
Manufacturer | Cisco Systems, Inc |
Manufacturer Part Number | C881GW+7-A-K9 |
Manufacturer Website Address | http://www.cisco.com |
Brand Name | Cisco |
Product Series | 880G |
Product Model | C881GW |
Product Name | C881GW Wireless Integrated Services Router |
Product Type | Wireless Integrated Services Router |
Technical Information | |
Wi-Fi Generation | Wi-Fi 4 |
Wireless Specifications | |
Broadband Transmission Technology | Cellular |
Broadband Transmission Technology | Ethernet |
Wireless LAN Standard | IEEE 802.11n |
ISM Band | Yes |
UNII Band | Yes |
ISM Maximum Frequency | 2.40 GHz |
UNII Maximum Frequency | 5 GHz |
Cellular Generation | 3G |
Cellular Network Supported | GSM 1800 |
Cellular Network Supported | WCDMA 900 |
Cellular Network Supported | WCDMA 2100 |
Cellular Network Supported | GSM 900 |
Cellular Network Supported | GSM 1900 |
Cellular Network Supported | WCDMA 1900 |
Cellular Network Supported | WCDMA 850 |
Cellular Network Supported | GSM 850 |
Cellular Data Connectivity Technology | EDGE |
Cellular Data Connectivity Technology | GPRS |
Cellular Data Connectivity Technology | HSPA |
Cellular Data Connectivity Technology | UMTS |
Cellular Data Connectivity Technology | HSPA+ |
Total Number of Antennas | 2 |
Antenna Type | Dipole Antenna |
Total Wireless Transmission Speed | 6.75 MB/s |
Features | MIMO Technology |
Features | Quality of Service (QoS) |
Interfaces/Ports | |
Number of Network (RJ-45) Ports | 4 |
Network (RJ-11) | No |
VGA | No |
USB | Yes |
Powerline | No |
PoE (RJ-45) Port | Yes |
Management Port | Yes |
Number of Broadband (RJ-45) Ports | 1 |
I/O Expansions | |
Total Number of Expansion Slots | 2 |
Expansion Slot Type | SIM Card |
Network & Communication | |
Ethernet Technology | Fast Ethernet |
Network Technology | 10/100Base-TX |
VPN Supported | Yes |
Management & Protocols | |
Management |
|
Security Features |
|
Power Description | |
Input Voltage | 12 V DC |
Power Source | AC Adapter |
Physical Characteristics | |
Form Factor | Desktop |
Height | 1.8" |
Width | 12.8" |
Depth | 9.8" |
Weight (Approximate) | 5.50 lb |
Miscellaneous | |
Certifications & Standards | Approvals:
Safety:
EMC:
Radio:
|
Warranty | |
Limited Warranty | 90 Day |
