LG LFCM039-GN VIRTUAL PRODUCTION LFCM SERIES DVLED, P3.91, 128X128 RESOLUTION, WORKS WITH MEGA
Mfg Part Number: LFCM039-GN , Item #: 5178004
, PO and Wire.
High Durability
LFCM is a unique display installed on the floor with high durability designed to load up to 1,500 kg/sqm.
Excellent Usability
Surface safety when installing the screen on the floor IP65 protective slip-resistant mat and reflection-reducing surfaces and high visual performance with high contrast LED for uniform visual performance in black are considered. New mask with diffusing powder has been applied for reducing the color shifting and refracting the light to various directions as considering its usage for XR Stage.
Easy Installation and Maintenance
The product features a simple structure that enables fast installation and easy maintenance. The cabinets can be easily deployed and connected using the foot support system. A straightforward flush control mechanism design helps to maintain consistent height levels on different types of floors. Additionally, the LED module is equipped with magnets for convenient maintenance, and hot swapping is possible even while the display is in operation.
Powerful UI/UX with
Megapixel VR HELIOS LED
Processing Platform
Thanks to the compatibility between LFCM and the Megapixel VR HELIOS LED processing platform, you can now utilize the powerful UX and UI functionalities offered by HELIOS. HELIOS processing platform includes Real-Time Mapping and Multi-User Control, Superior Color Control, Hyper-Speed Seam Correction using a game controller, and Monitoring and Diagnostics through connected diagnostics.
| General Information | |
| Manufacturer | LG Electronics |
| Manufacturer Part Number | LFCM039-GN |
| Manufacturer Website Address | https://solutions.lg.com/us |
| Brand Name | LG |
| Product Model | LFCM039-GN |
| Product Name | LFCM Floor Direct View LED compatible with Megapixel VR Helios Controller |
| Product Type | Digital Signage Display |
| Technical Information | |
| Average Heat Dissipation Per Cabinet | 80.01 W |
| Ingress Protection (IP) Rating | IP65 |
| Minimum Color Temperature | 5840.3°F (3226.8°C) |
| Maximum Color Temperature | 15740.3°F (8726.8°C) |
| Color Uniformity | ±0.003 Cx, Cy |
| Service Access | Front |
| Display & Graphics | |
| Display Resolution | 128 x 128 |
| Pixel Pitch | 0.15" |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 160° |
| Cabinet Surface Area | 3 Sq. ft. |
| Number of Modules Per Cabinet | 2x2 |
| Module Resolution | 64 x 64 |
| Maximum LED Life | 11.4 Year |
| LED Type | Single SMD |
| Physical Pixel Density | 65536 pixels/m² |
| Video | |
| Standard Refresh Rate | 3.84 kHz |
| Frame Refresh Rate | 60 Hz |
| Native Contrast Ratio | 5,000:1 |
| Brightness | 1500 Nit |
| Power Description | |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 113°F (45°C) |
| Minimum Operating Humidity | 0% |
| Maximum Operating Humidity | 80% |
| Physical Characteristics | |
| Height | 19.7" |
| Width | 19.7" |
| Depth | 3.3" |
| Module Height | 9.80" |
| Module Width | 9.80" |
| Weight per Module (Approximate) | 2 lb |
| Weight per Cabinet (Approximate) | 23.10 lb |
| Housing Material | Die-cast Aluminum |
| Weight per Square Meter (Approximate) | 48000 g/m² |
| Miscellaneous | |
| Additional Information | |
| Certifications & Standards | |
| Environmentally Friendly | Yes |
| Environmental Certification | REACH |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TAA Compliant | No |
| Warranty | |
| Limited Warranty | 3 Year |
