Axis

02623-001 AXIS M1137-E MK II I-CS

Mfg Part Number:  02623-001
Image may not reflect the actual item.
Price: $844.72 + Free Shipping
Quantity:
In Stock: 5
Last Updated: Jul 22, 2025
No Sales Tax except these states
, PO and Wire.

This compact, outdoor-ready box camera delivers 5 MP resolution with superb image quality even in low light conditions. Designed as a visible deterrent, it helps discourage trespassing and other unwanted activities.

More bang for your buck

This affordable Axis M-line camera offers audio input allowing you to record video with sound. Thanks to support for PoE and redundant DC power, you get flexible installation, and your data is safeguarded in the event of a power outage. It includes signed firmware and secure boot to ensure only authorized firmware is installed and that the firmware hasn't been compromised. And, Axis Zipstream with support for H.264/H.265 significantly reduces bandwidth and storage requirements. Furthermore, it comes with AXIS Object Analytics preinstalled, so you can detect and classify humans and vehicles.

Great image quality even in low light

With 5 MP resolution at up to 30 fps, AXIS M1137-E Mk II delivers superb video quality even in low light conditions. Featuring Axis Lightfinder it offers images in true colors even in low light. And, with Axis Forensic WDR you get clarity even when there's both dark and light areas in the scene. Ideal for various surveillance situations, it includes a CS-mount with support for motorized i-CS lenses, enabling remote zoom. Use our lens calculator to select a lens that meets your specific requirements.

Designed for deterrence

This outdoor-ready camera comes enclosed in an IP66-, IK10- and NEMA 4X-rated casing to protect against water, corrosion, dust, and impacts. Designed to act as a deterrent, it lets potential offenders know you're watching and helps prevent unwanted activities. Furthermore, AXIS M1137-E Mk II provides a clearly visible, fixed angle of view, making it easy to see exactly where the camera's pointing and allowing you to record both audio and video in a precisely defined area. And, thanks to edge-to-edge technology it can be connected to Axis speakers, such as an Axis horn speaker.

Main Specification
General Information
Manufacturer Axis Communications
Manufacturer Part Number 02623-001
Manufacturer Website Address http://www.axis.com
Brand Name AXIS
Product Series M11
Product Model M1137-E Mk II
Product Name M1137-E Mk II Box Camera
Product Type Network Camera
Technical Information
HD Recording Yes
Display & Graphics
Image Sensor Type RGB CMOS
Image Sensor Size 1/2.7"
Color Supported Color
Field of View 99°-31° / 71°-24°
Effective Camera Resolution 5 Megapixel
Video
Video Formats H.264 (MPEG-4 Part 10/AVC)
Video Formats H.265 (MPEG-H Part 2/HEVC)
Video Formats H.265
Video Formats H.264
Video Formats Zipstream
Video Formats Motion JPEG
Maximum Video Resolution 2592 x 1944
Maximum Frame Rate 30 fps
Lens
Lens Type Varifocal
Minimum Focal Length 3.50 mm
Maximum Focal Length 10 mm
Lens Included Yes
Lens Mount Type CS-Mount
Optical Zoom 2.9x
Exposure
Shortest Shutter Speed 1/33500 Second
Longest Shutter Speed 1/5 Second
Network & Communication
Connectivity Technology Wired
Ethernet Technology Fast Ethernet
Remote Management Yes
Storage
Storage Type Memory Card
Interfaces/Ports
Network (RJ-45) Yes
Power Description
Input Voltage 28 V DC
Input Voltage 10 V DC
Power Source Type DC
Power Source Type PoE
Physical Characteristics
Mount Type Wall Mount
Form Factor Box
Durability Impact Resistant
Durability Corrosion Resistant
Durability Water Resistant
Durability Dust Resistant
Color Family White
Product Color White
Weight (Approximate) 3.97 lb
Environmental Conditions
Minimum Operating Temperature -13°F (-25°C)
Maximum Operating Temperature 122°F (50°C)
Maximum Operating Humidity 100%
Miscellaneous
Features Audio Detection
Features Privacy Masking
Features Wide Dynamic Range
Features Password Protection
Features Mirror
Features Day/Night
Features Tampering Alarm
Features Vehicle Detection
Features Built-in Microphone
Features SD Card Local Storage
Indoor/Outdoor Outdoor
Package Contents
  • M1137-E Mk II Box Camera
  • AXIS T94Q01A Wall Mount
  • Torx® T20 screw driver
  • Torx® T30 screw bit
  • connector kit
  • installation guide
  • Windows decoder 1-user license
Impact Protection Rating IK10
Ingress Protection Rating IP66
Warranty
Limited Warranty 5 Year
