VERTIV
VERTIV ACS8048-NA-DAC-400 48PT ACS8000 4G/LTE NA2 DUALAC TAA
Mfg Part Number: ACS8048-NA-DAC-400 , Item #: 4231505
, PO and Wire.
The Vertiv Avocent ACS8000 Cellular advanced serial console server series delivers secure in-band and out-of-band visibility and control to downstream equipment in enterprise data centers, as well as cloud and colocation facilities. Now with cellular capabilities, the Vertiv Avocent ACS8000 Cellular provides flexibility to access devices when wired networks are down (failover) or not available at the device location. This serial console system serves as a secure management gateway and single point of entry keeping you connected to critical IT equipment even in the event of partial or total data center outages. With environmental monitoring, IoT integration, and remote networking abilities, the Vertiv Avocent ACS8000 Cellular is ideal for edge locations, enterprise data centers, and hyperscale or colocation facilities.
| General Information | |
| Manufacturer | Vertiv |
| Manufacturer Part Number | ACS8048-NA-DAC-400 |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Brand Name | Vertiv AVOCENT |
| Product Series | ACS 8000 |
| Product Model | ACS8048-NA-DAC-400 |
| Product Name | ACS8000 Advanced Console Server |
| Product Type | Device Server |
| Technical Information | |
| Device Type | Console Server |
| Memory | |
| Standard Memory | 1000 MB |
| Memory Technology | DDR3L SDRAM |
| Maximum Memory Supported | 16 GB |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Standard | 10/100/1000Base-T |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| USB | Yes |
| Serial Port | Yes |
| Management Port | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of USB Ports | 8 |
| Number of Serial Ports | 48 |
| Power Description | |
| Power Consumption | 28 W |
| Physical Characteristics | |
| Height | 1.8" |
| Width | 17.3" |
| Depth | 9.5" |
| Weight (Approximate) | 7.20 lb |
| Miscellaneous | |
| Additional Information | 1 x Full Size SD Card Slot 4 Digital-In Ports (Smoke, Leak, Pressure And Dry Contact Sensors) Optional 48V DC Power Supply Cellular Type: 4G/LTE (2FF/mini SIM Card Slot) Cellular Frequency Bands (MHz):
|
| Compatibility |
|
| Country of Origin | United States |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 1 Year |
