CISCO UCS-SPC240M5L-S1 SP C240 M5L W/ 2X4110 6X16GB MEM VIC1387
Mfg Part Number: UCS-SPC240M5L-S1 , Item #: 2971049
, PO and Wire.
The UCS C240 M5 LFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the addition of the 2nd Generation Intel® Xeon® Scalable Processors, 2933-MHz DDR4 memory, and the new 512GB Intel® Optane™ Persistent Memory (PMem). With this combination of features, up to 9 TB of memory is possible (using 12 x 256 GB DDR4 DIMMs and 12 x 512 GB PMem), up to 6 PCI Express (PCIe) 3.0 slots, and up to 12 front-facing internal LFF drives. The C240 M5 LFF server also includes one dedicated internal slot for a 12G SAS storage controller card.
The C240 M5 server includes a dedicated modular LAN on motherboard (mLOM) slot for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC) without consuming a PCI slot, in addition to 2 x 10 Intel x550 10Gbase-T embedded (on the motherboard) LOM ports.
The Cisco UCS C240 M5 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.
| General Information | |
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | UCSSPC240M5LS1 |
| Manufacturer Website Address | http://www.cisco.com |
| Brand Name | Cisco |
| Product Series | C240 M5 |
| Product Name | UCS C240 M5 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 2 |
| Processor Type | Xeon Silver |
| Processor Generation | 2nd Gen |
| Processor Model | 4110 |
| Processor Core | Octa-core (8 Core) |
| Processor Speed | 2.10 GHz |
| Cache | 11 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Memory | |
| Standard Memory | 96 GB |
| Maximum Memory Supported | 9 TB |
| Memory Technology | DDR4 SDRAM |
| Error Checking | ECC |
| Number of Occupied Memory Slots | 6 |
| Signal Processing | Registered (Buffered) |
| Controllers | |
| Controller Type | 12Gb/s SAS |
| I/O Expansions | |
| Number of Total Expansion Bays | 12 |
| Number of 3.5" Bays | 12 |
| Number of LFF Bays | 12 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 6 |
| PCI Express Details | Up to six PCIe slots (on two riser cards) |
| Display & Graphics | |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | 40 Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| VGA | Yes |
| Number of VGA Ports | 1 |
| Remote Management | Yes |
| Remote Management Controller | Baseboard Management Controller (BMC) |
| Operating System | |
| Operating System Supported | Windows Server 2022 Standard |
| Operating System Supported | SuSE Linux Enterprise Server |
| Operating System Supported | Windows Server 2019 Datacenter |
| Operating System Supported | Red Hat Enterprise Linux |
| Operating System Supported | Windows Server 2022 Datacenter |
| Operating System Supported | Windows Server 2019 Standard |
| Power Description | |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Number of Power Supplies Supported | 2 |
| Plug/Connector Type | C13 |
| Hot Swappable Power Supply | Yes |
| Power Source | Power Supply |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 2U |
| Height | 3.4" |
| Width | 19" |
| Depth | 30.4" |
| Weight (Approximate) | 66 lb |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information |
|
