CISCO
CISCO UCS-SA-C240M3S-202 UCS C240M3S W/ 2XE52660V2 24X16GB MEM
Mfg Part Number: UCS-SA-C240M3S-202 , Item #: 2138237
Image may not reflect the actual item.
Price: $24,847.02
+ Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: Jan 09, 2026
No Sales Tax except these states
, PO and Wire.
The UCS C240 M3 rack server is designed for both performance and expandability over a wide range of storage-intensive infrastructure workloads from big data to collaboration.
The enterprise-class UCS C240 M3 server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the addition of the Intel® Xeon E5-2600 v2 and E5-2600 series processor family CPUs that deliver the best combination of performance, flexibility and efficiency gains. In addition, the UCS C240 M3 server provides 24 DIMM slots, up to 24 drives and 4 x 1 GbE LOM ports to provide outstanding levels of internal memory and storage expandability along with exceptional performance.
Main Specification
| General Information | |
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | UCSSAC240M3S202 |
| Manufacturer Website Address | http://www.cisco.com |
| Brand Name | Cisco |
| Product Series | C240 M3 |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 2 |
| Processor Type | Xeon |
| Processor Model | E5-2660 v2 |
| Processor Core | Deca-core (10 Core) |
| Processor Speed | 2.20 GHz |
| Cache | 25 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C600 |
| Memory | |
| Standard Memory | 384 GB |
| Maximum Memory Supported | 768 GB |
| Memory Technology | DDR3 SDRAM |
| Memory Clock Speed | 1.60 GHz |
| Error Checking | ECC |
| Total Number of Memory Slots | 24 |
| Number of Occupied Memory Slots | 24 |
| Signal Processing | Registered (Buffered) |
| Storage | |
| Number of Hard Drives | 14 |
| Total Hard Drive Capacity | 12.30 TB |
| Hard Drive Interface | 6Gb/s SAS |
| Hard Drive Configuration | 14 x 900GB |
| Number of Solid State Drives | 2 |
| Total Solid State Drive Capacity | 800 GB |
| Solid State Drive Interface | 6Gb/s SAS |
| Solid State Drive Configuration | 2 x 400GB |
| Controllers | |
| Controller Type | 6Gb/s SAS |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 6, 10 |
| I/O Expansions | |
| Number of Total Expansion Bays | 24 |
| Number of Internal 2.5" Bays | 24 |
| Number of SFF Bays | 24 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 5 |
| PCI Express x16 (Gen 3.x) Slots | 3 |
| Display & Graphics | |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 256 MB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 2 |
| Number of USB 2.0 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 4 |
| VGA | Yes |
| Number of VGA Ports | 1 |
| Remote Management | Yes |
| Remote Management Controller | Cisco Integrated Management Controller (CIMC) |
| Power Description | |
| Input Voltage | 230 V AC |
| Input Voltage | 120 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Plug/Connector Type | IEC 320-C14 |
| Maximum Power Supply Wattage | 1200 W |
| Redundant Power Supply | Yes |
| Power Source | Power Supply |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.4" |
| Width | 17.5" |
| Depth | 28" |
| Weight (Approximate) | 60 lb |
| Warranty | |
| Additional Warranty Information |
|
