DRS1215 Tripp Lite DRS-1215 14 Outlets 120V Surge Suppressor

Tripp Lite's DRS-1215 offers surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Includes 14 outlets (6 front/8 rear), 15-ft. (4.57 m) AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LED indicates surge protection status.

PLUG/OUTLETS: Input: NEMA 5-15P/Output: 14 NEMA5-15R (6 front & 8 rear)

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle)

SUPPRESSION: AC: 140V RMS Clamping/3000 joules

FORMAT: Supports 19 in. rackmount (uses 1 rack space/1U), wallmount, under-counter and more

Features

• Versatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options
• Uses one rack space (1U) in standard 19 inch rack ("zero U" mounting possible in many racks)
• 3000 joules AC surge suppression with EMI/RFI filtering
• 14 NEMA 5-15R output receptacles (6 front/8 rear)
• 15-ft. (4.57 m) AC cord with NEMA 5-15P straight-in plug connection
• Diagnostic LED confirms suppressor operation
• Lighted power switch confirms power on/off status
• Snap-in switch guard prevents accidental turn off
• 15 amp capacity with circuit breaker
• 120V AC, 50/60Hz electrical compatibility

More from the Manufacturer

General Information
Manufacturer	Eaton Corporation
Manufacturer Part Number	DRS-1215
Manufacturer Website Address	http://www.eaton.com
Brand Name	Tripp Lite by Eaton
Product Name	DRS-1215 14 Outlets 120V Surge Suppressor
Product Type	Surge Suppressor/Protector
Technical Information
Plug/Connector Type	NEMA 5-15P
Receptacles	14 x NEMA 5-15R
Protection Type	Surge
Power Description
Input Voltage	120 V AC
Output Voltage	120 V AC
Maximum Line Current	15 A
Power Handling	1800 VA
Surge Energy Rating	3000 J
Circuit Breaker	Yes
Physical Characteristics
Color Family	Black
Product Color	Black
Product Material	Metal
Power Cord/Cable Length	15 ft
Form Factor	Rack-mountable
Height	1.8"
Width	17.5"
Depth	4"
Weight (Approximate)	4.60 lb
Miscellaneous
Package Contents	DRS-1215 14 Outlets 120V Surge Suppressor Warranty information Instruction manual
Additional Information	Snap-in switch guard prevents accidental turn off
Compatibility	Ideal for protection of sensitive electronic equipment in 19 inch rackmount, wallmount and under-counter applications, such as internetworking equipment, PC systems, telecommunications, audio/video, security and sound reinforcement
Certifications & Standards	UL1449 (Let through rating 330V) cUL IEEE 587 category A and B specifications
Country of Origin	China
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty	Lifetime

General Information
Product	-
Number of Outlets	14
Surge Energy Rating	1050 J
Data Line Protection	Not Protected
Cord Length	15 ft
Mounting Style	Rack
Output Voltage	120 V
Current Rating	15 A

Tripp Lite's DRS-1215 offers surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Includes 12 outlets (6 front / 6 rear), 15 ft AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LED indicates surge protection status. Lifetime warranty.
Key Buying Points:
Versatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options
Uses one rack space (1U) in standard 19 inch rack ("zero U" mounting possible in many racks)
450 joules AC surge suppression with EMI/RFI filtering
12 NEMA 5-15R output receptacles (6 front / 6 rear)
15 foot AC cord with NEMA 5-15P straight-in plug connection
Diagnostic LED confirms suppressor operation
Lighted power switch confirms power on/off status
Snap-in switch guard prevents accidental turn off
15 amp capacity with circuit breaker
120VAC, 50/60Hz electrical compatibility
Lifetime product warranty

Typical Applications:
Ideal for protection of sensitive electronic equipment in 19 inch rackmount, wallmount and under-counter applications, such as internetworking equipment, PC systems, telecommunications, audio/video, security, sound reinforcement and more.

Package Includes:
DRS-1215 surge suppressor
Warranty information
Instruction manual
Dimensions

Dimensions: 1.75" x 19" x 4.5"

Region/Country Support

Region/Country Support : North America

UPS & Surge Suppressors

AC Receptacles (Surge Only): 12
Cord Length : 15 feet
Energy Rating (Joules): 450
Frequency (Input): 50/60
Frequency (Output): 50/60
Voltage (Input): 120
Voltage (Output): 120

Warranty Information

Warranty Terms: Limited lifetime
