KT-ES212X12HP SANS DIGITAL ES212X12HP 12G SAS ES212X12 2U 12BAY W/ 12G RAID CARD
Mfg Part Number: KT-ES212X12HP , Item #: 1713080
Image may not reflect the actual item.
Price: $5,131.23
+ Free Shipping
Quantity:
In Stock/Mfg Direct Ship
Last Updated: May 31, 2025
No Sales Tax except these states
, PO and Wire.
The EliteSTOR ES212X12HP is a complete 2U 12G SAS RAID solution for performance hungry RAID storage solution. Utilizing the latest 12G SAS expander technology, the ES212X12HP provides up to 48Gb/s or 4800MB/s of data bandwidth to fulfill the most demanding application. The ES212X12HP supports SATA or SAS 12Gb/s hard drives or SSD and is backward compatible to 6Gb/s SAS & SATA hard drives. By utilizing the latest SAS expander technology, the ES212X12HP supports up to 12 SAS or SATA drives using only one HD mini-SAS (SFF-8644) cable. A built-in SAS expansion port enables the system to connect up to 256 drives drives daisy-chained together. The system comes with a high performance RAID controller card, and the ES212X12HP is capable of delivering over in 3,000MB/s read and write performance, doubling the existing 6G SAS expander bandwidth. Dedicated dual-core RAID engines provides RAID 0, 1, 3, 5, 6, 10, 50, 60 support with enterprises features and performances. System status information is provided by the LED, including hard drives, power supply and cooling fan status, as well as RAID controller's event log and e-mail notification system. All necessary hardware comes standard including RAID controller card, mini-SAS cable, hard drives tray modules and built-in mounting rail. The ES212X12HP is an ideal storage expansion solution for servers or high performance video editing workstations. Support Windows (Vista or up, Server 2003 or up), Apple (OS X 10.4 or up), Linux and BSD. VMware ESX and Microsoft Hyper-V is also supported.
Main Specification
| General Information | |
| Manufacturer | Sans Digital |
| Manufacturer Part Number | KT-ES212X12HP |
| Manufacturer Website Address | http://www.sansdigital.com |
| Brand Name | Sans Digital |
| Product Line | EliteSTOR |
| Product Model | ES212X12HP |
| Product Name | EliteSTOR ES212X12HP DAS Array |
| Product Type | DAS Storage System |
| Storage | |
| Number of Hard Drives Supported | 12 |
| Total Hard Drive Capacity Supported | 48 TB |
| Number of Solid State Drive Supported | 12 |
| I/O Expansions | |
| Number of Total Expansion Bays | 12 |
| Number of 3.5" Bays | 12 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 3, 5, 6, 10, 30, 50, 60, 100, 1E, JBOD |
| Interfaces/Ports | |
| Host Interface | Mini-SAS |
| Power Description | |
| Power Source | Power Supply |
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 380 W |
| Redundant Power Supply | Yes |
| Physical Characteristics | |
| Height | 3.5" |
| Width | 19" |
| Depth | 23" |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Weight (Approximate) | 35 lb |
| Miscellaneous | |
| Package Contents |
|
| Certifications & Standards |
|
| Platform Supported | PC |
| Platform Supported | Mac |
| Environmentally Friendly | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
