ST1000SPEX2L StarTech.com 1 Port PCI Express PCIe Gigabit NIC Server Adapter Network Card - Low Profile

The ST1000SPEX2L Low-Profile PCIe Gigabit Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface. Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter offers effective network performance. The card comes pre-configured with a low-profile/half-height installation bracket and includes a standard profile bracket for installation in a wide range of computer/server chassis, regardless of form factor. Backed by a 2-year StarTech.com warranty and free lifetime technical support. More from the Manufacturer

More from the Manufacturer

General Information
Manufacturer	StarTech.com
Manufacturer Part Number	ST1000SPEX2L
Manufacturer Website Address	http://www.startech.com
Brand Name	StarTech.com
Product Name	1 Port PCI Express PCIe Gigabit NIC Server Adapter Network Card - Low Profile
Packaged Quantity	1 Each
Product Type	Gigabit Ethernet Card
Technical Information
Chipset Manufacturer	Realtek
Chipset Model	RTL8111
Interfaces/Ports
Host Interface	PCI Express
Total Number of Ports	1
Network (RJ-45)	Yes
USB	No
Serial Port	No
Ethernet AUI	No
XJACK	No
PoE (RJ-45) Port	No
Number of Network (RJ-45) Ports	1
Media & Performance
Media Type Supported	Twisted Pair
Maximum Data Transfer Rate	8 Gbit/s
Network & Communication
Network Technology	10/100/1000Base-T
Physical Characteristics
Card Length	Half-length
Card Height	Low-profile
Form Factor	Plug-in Card
Height	1.9"
Width	0.7"
Length	2.8"
Thickness	700 mil
Weight (Approximate)	1 oz
Miscellaneous
Package Contents	1 Port PCI Express PCIe Gigabit NIC Server Adapter Network Card - Low Profile 1 x Standard Profile Bracket 1 x Instruction Manual
Device Supported	PC
System Requirements	Windows® 2000, XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 Mac OS X® 10.6 to 10.9 Linux 2.4.x to 4.11.x LTS Versions Only
Environmentally Friendly	Yes
Environmental Certification	EU RoHS
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)
Environmental Compliance	Restriction of Hazardous Substances (RoHS) 2
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Country of Origin	China
End of Life Manual Availability	Yes
EU RoHS Declaration URL	https://media.startech.com/cms/pdfs/st1000spex2l_rohs.pdf
REACH Declaration URL	https://media.startech.com/cms/pdfs/st1000spex2l_rohs.pdf
REACH free of SVHC	Yes
WEEE Statement	https://media.startech.com/cms/pdfs/st1000spex2l_weee.pdf
Warranty
Limited Warranty	2 Year
