The Rack Slide Kit designed to be used with Magma's 6, 7 and 13 Slot PCI expansion chassis and the ExpressBox 7.

Magma's ExpressBox 16 is the simplest solution to seamlessly increase the number of PCI Express® slots available to your server or workstation. ExpressBox 16 expands one host PCIe® slot to sixteen slots by extending PCI Express signals over a high-bandwidth x8 or x16 connection to an external Magma enclosure.

ExpressBox 16 consists of a pair of interface cards (x8 or x16), an iPass cable and a 4U rack-mount expansion chassis. The Magma expansion chassis is automatically configured by the System BIOS, with the expansion slots appearing transparently on the host computer.

Benefits:

• Industrial solution for adding up to sixteen PCI Express slots to one computer
• Attach full-length PCI Express cards computers with limited card space
• Daisy chain or fan out multiple expansion chassis to one computer
• Low profile host card allows for easy installation in low profile computers

Features:

• Easy "Plug and Play" installation
• Supports peer-to-peer transfers between cards in the expansion chassis to provide full bandwidth potential among I/O cards
• LEDs on backplane indicate: active link, speed (Gen 1 or Gen 2), partial or complete lane training
• Industrial 4U rack-mount enclosure
• Four dedicated cooling fans with thermistor-controlled fan speeds to reduce unnecessary noise
• Multiple power supply options with auxiliary power connectors to support cards requiring more than 75 Watts

Protect your investment and keep your PCI cards in commission with our 3 slot PCI expansion chassis. Expand the life of your PCI cards by keeping them protected and running in optimal conditions.

Need to upgrade your server or desktop computer? Don't want to lose your investment in your specialized PCI cards that won't fit in your new computer? You can install practically any PCI card into the Magma PCI Expansion System and connect it through a PCI Express slot on your computer.

Prolong Your Investment

Magma's 3 Slot PCI Expansion System provides a simple, cost-effective solution for expanding the capability of practically any computer, especially as PCI Express becomes the industry standard, the number of available PCI slots has been reduced or completely eliminated. Many companies have invested a lot time, energy and money in solutions built around conventional PCI hardware. The Magma 3 Slot PCI Expansion System provides a safe "migration path" to PCI Express while protecting your investment in PCI cards.

Save Time, Money and Trouble

The expansion chassis consists of a host interface card, a cable and a chassis. The expansion chassis is automatically configured by the System BIOS making all of the slots appear transparent within the host computer.

Cost-Effective Migration and Increased I/O Capacity

Magma expansion solutions provide a cost-effective migration path to new computers while maintaining a consistent PCI configuration. In addition, Magma products significantly increase (I/O) capacity and scalability. Multiple expansion systems can be combined to provide an almost unlimited number of PCI slots* to a single computer. This type of scalability is especially useful in industries such as Telecom, Data Acquisition, Video Monitoring, Server Storage and Manufacturing Test Fixtures.

Benefits:

• Increase the number of PCI slots without replacing your computer
• Attach full-height PCI cards to computers with low-profile slots or PCI Express slots
• The only solution for adding multiple PCI cards to mobile computers
• Multiple expansion systems can be connected to a single computer
• Keep your PCI configuration consistent making computer upgrades easy
• Proven method to increase PCI capability without losing performance

Features:

• Connects to desktop and laptop computers
• 3 slot PCI 64-bit Backplane
• All slots support full-length or shorter universal and legacy 5 volt only PCI cards (optional 3.3V only available)
• Quiet cooling for hot PCI cards
• All Slots support full length (12.283") or shorter PCI cards
• Versatile black enclosure can be rack-mounted or stacked on a tabletop under your computer or monitor
• Non-enclosed board sets are available for OEMs and System Integrators to utilize their own enclosure
• Only 2U when rack-mounted and brackets are included

The Rack Slide Kit designed to be used with Magma's 6, 7 and 13 Slot PCI expansion chassis and the ExpressBox 7.

This 10 slot rackmount expansion platform provides GPU expansion at a value price.

The 4UV supports 2 PCIe 3.0 x16 host connections to 10 PCIe 3.0 x16 slots with two 1m cables to the host server. The system supports 8 double width GPUs or 10 single slot GPUs or add-in boards. Two fan choices allow for high-power GPU cooling up to 300W per GPU or a set-and-forget manual speed control using PWM fans when lower power GPUs or add-in cards are used. Two 2000W power supplies provide up to 4000W of usable power to the GPU accelerator system.

Features:

• 4U rackmount design
• 10 PCIe 3.0 x16 expansion slots
• Two PCIe 3.0 x16 host connections
• Two PCIe 1m cables
• Tach and PWM fan options
• Two 2000W load-sharing power supplies
• Eight EPS12V PCIe power connectors
