Near UV, Visible, Near IR 1,000nm transmittance.

Advanced capabilities for law enforcement, military, security, covert surveillance,
any application requiring extreme low-light imaging.

Telephoto 140mm focal length, aperture F1.0 super low light near IR 1,000nm performance image quality used with low lux or near IR cameras. This lens / camera combination provides performance approaching military amplified light scope devices at a fraction of the cost.

• Telephoto super low light 1,000nm imaging in near zero ambient lighting conditions with low lux / near IR cameras.
• Greater low light optical image performance compared to military amplified light scopes.
• Glass optical, anodized aluminum housing, heavy duty design and build quality.
• Used by law enforcement, military, security organizations worldwide for telephoto applications in low to near zero lighting conditions.

The Marshall V-702W dual 7" LCD Display is a feature-packed, economical solution perfect for fly-packs, control rooms, routing rooms and countless other video system applications. The V-702W adds multiple analysis functions to a monitors with great images and pricing. Features like Waveform Monitor, Vectorscope, Audio Phase, HDR modes, S-Log conversions and user LUT's (with split-screen comparison) makes this monitor a versatile QC platform.

Dual Full HD Screens

Two High-Definition screens with excellent color rendition and stability. Adjustable back light compensates for different viewing environments.

Split-Screen Comparison

Compare HDR, Gamma and S-Log scene corrections side-by-side. See "before and after" effect in real-time

Great Off-Axis Performance

Excellent angle of viewing allows the user to position the rack in any number of physical locations.

The VAC-12HUC converts a HDMI input to USB-C (3.0) high quality output. The input has an active loop-through allowing the original full-quality source to be routed to monitors or other equipment. Common applications include live screen capture, video conferencing and other PC based functions. Power is supplied by the USB connection eliminating the need for an external power supply.

A rugged metal case makes this converter suitable for field use.

• The HDMI input accepts SD/HD up to 1080p50/60 and 4K up to 4096x2160@30fps
• USB-C output video format is controlled by the particular application running on the PC
• Depending on the application's settings and limitations, outputs up to 3840x2160@30fps are possible
• Output audio sampling rate defaults to 48KHz
• Stereo audio input via 3.5mm jack
• Backwards compatible to USB 2.0 (limited to 1280x720p30 max)
• Supported operating systems: Windows 10, 11, Mac OS
• Plug and Play operation. No special drivers required.

The Marshall ML-454-V2 Quad 4.5" Screens LCD Display is a feature-packed, economical solution perfect for fly-packs, control rooms, routing rooms and countless other video system applications. Looping video inputs set this product apart from similar-looking products. With the ML-454-V2, you are not limited to the single SDI connector you may find on competitor models. Standard power and tally connections as well as a logical menu structure make this display an easy choice for flexible system designs.

Four 4.5" HD Screens

Four high compliance 3G panels provide full time viewing access to multiple production sources with very accurate rendition. The panels are easily matched and and maintain calibration almost indefinitely.

On-Screen 3 Color Tallies

Easily visible border tallies provide instantaneous process control feedback to the operator.

Compact Panel 2RU (3.5") Height

Rugged, all metal construction makes the ML-454-V2 at home in any rack mount or standalone application.

Great Off-Axis Performance

Excellent angle of viewing allows the user to position the rack in any number of physical locations.

Marshall CV620-TBI/TWI PTZ camera features an ability to automatically track, follow and frame presenters using AI facial learning process for more accurate and smoother self-adjusting maneuvers. Equipped with a more than capable 20x optical zoom range from 60-degrees wide open to roughly 3-degrees telephoto. Flexible networkable IP interface with simultaneous 3GSDI and HDMI outputs. One ethernet (Cat) cable installation with PoE+ simplifies setup and operation.

AI Track, Follow and Frame

Designed to auto-track, follow and frame presenters using more natural and smooth maneuvers. Utilizing new AI technology to recognize faces and learn movement dynamics of the subject to anticipate motion, accurately follow and frame subjects with smooth transitions, therefore reducing viewer irritation and fatigue.

Crisp Full-HD Video Output

The CV620 is built around a professional-grade 2-Megapixel 1/2.8-inch Sony sensor with smooth 20x Optical Zoom (5.3~110mm) producing clear HD video up to 1920x1080p60fps, 1920x1080i and 1280x720p. Smart AI auto-focus identifies faces and maintains accurate and sharp focus of subjects.

Versatile Camera Position

The CV620 is equipped with synchronous pan, tilt, and zoom motors with various speed adjustment for smooth and silent camera movements during operation. Ultra-wide 340° pan range and 120° tilt provides a wide range of movement. 20X optical zoom provides flexibility from 5.3mm to 110mm, maintaining image crispness in wide and tight shots.

Easy I/O and Control
Simultaneous IP, 3GSDI and HDMI outputs with a wide range of remote command and control options. Locally with IR remote, Video Management Software (VMS), Software GUI over web, VS-PTC-IP controllers, OBS plugins and many 3rd party control decks and codecs using Visca over IP/RS232/RS422. Also easy one-cable to camera setup via IP ethernet cable for control, video, audio, tally and PoE+ (power).

Compact UHD Camera with large 1/1.8" 4K sensor with 9.2 megapixel and ePTZ maneuverable functionality built into a durable compact size. Featuring easy one-cable IP setup, USB3.0 connectivity and HDMI simultaneous output. Ultra-wide 100-degree AOV with no curvature option wide open and ability to ePTZ an HD image within the 4K sensor.

Crystal Clear 4K Images with wide AOV
Incorporating a 1/1.8" 4K sensor with over 9 million pixels delivers unparalleled clarity and performance even in challenging light conditions. Starting at a 100° angle-of-view CV420e delivers an ultra-wide perspective with no curvature.

Flexible Workflow Options

The flexibility to stream content over IP (HEVC) with an HDMI simultaneous output, or USB3.0 with a simultaneous HDMI output offers flexibility for media streaming and collaboration from one camera. Stream live to YouTube, Livestream, Facebook (Meta), or Twitch while capturing local HDMI content and workflow manipulation.

ePTZ with digital pan, tilt and zoom

Utilizing a large Sony 1/1.8" 4K sensor opens optional ePTZ maneuverability of HD images within the 4K sensor space. Controllable remotely via VMS, GUI, or Visca over IP command from 3rd party control decks as well as UVC commands over USB. Hardware control from Marshall VS-PTC-IP controller via IP and locally by IR remote included in box.

Durable, Flexible, Powerful

The CV420e is built into a compact and durable body with rear I/O protection wings. Marshall CVM-5 monitor mount and desktop stand is included (free) as well as IR remote for local setup and control. Compact, durable and powerful tool for a wide variety of streaming applications.

Marshall CV620-TBI/TWI PTZ camera features an ability to automatically track, follow and frame presenters using AI facial learning process for more accurate and smoother self-adjusting maneuvers. Equipped with a more than capable 20x optical zoom range from 60-degrees wide open to roughly 3-degrees telephoto. Flexible networkable IP interface with simultaneous 3GSDI and HDMI outputs. One ethernet (Cat) cable installation with PoE+ simplifies setup and operation.

AI Track, Follow and Frame

Designed to auto-track, follow and frame presenters using more natural and smooth maneuvers. Utilizing new AI technology to recognize faces and learn movement dynamics of the subject to anticipate motion, accurately follow and frame subjects with smooth transitions, therefore reducing viewer irritation and fatigue.

Crisp Full-HD Video Output

The CV620 is built around a professional-grade 2-Megapixel 1/2.8-inch Sony sensor with smooth 20x Optical Zoom (5.3~110mm) producing clear HD video up to 1920x1080p60fps, 1920x1080i and 1280x720p. Smart AI auto-focus identifies faces and maintains accurate and sharp focus of subjects.

Versatile Camera Position

The CV620 is equipped with synchronous pan, tilt, and zoom motors with various speed adjustment for smooth and silent camera movements during operation. Ultra-wide 340° pan range and 120° tilt provides a wide range of movement. 20X optical zoom provides flexibility from 5.3mm to 110mm, maintaining image crispness in wide and tight shots.

Easy I/O and Control
Simultaneous IP, 3GSDI and HDMI outputs with a wide range of remote command and control options. Locally with IR remote, Video Management Software (VMS), Software GUI over web, VS-PTC-IP controllers, OBS plugins and many 3rd party control decks and codecs using Visca over IP/RS232/RS422. Also easy one-cable to camera setup via IP ethernet cable for control, video, audio, tally and PoE+ (power).

The 4th generation Marshall CV620 HD PTZ Camera captures crisp HD video with the added versatility of a smooth pan-tilt-zoom chassis and 20X optical zoom block. Designed for high performance applications including broadcast television, live events, corporate installations, and more. Additionally, the CV620 includes precise picture adjustment settings and professional 3G/HDSDI and HDMI outputs for convenient integration and installation.

Crisp HD Video Output

The CV620 is built around a professional-grade, 2-Megapixel 1/2.8-inch sensor, with smooth 20x Optical Zoom (5.3~110mm) outputting HD video up to 1920x1080p, 1920x1080i and 1280x720p at 60fps.

Versatile Camera Positioning

The CV620 is equipped with synchronous pan, tilt, and zoom motors for smooth and silent camera movements during operation. A 20X optical zoom block provides flexibility from 5.3mm to 110mm, maintaining image crispness in wide and tight shots.

Professional Outputs and Control Interface

Simultaneous 3G/HDSDI and HDMI outputs with control options over RS-422, RS-232, or IR remote control provide flexibility for inclusion in most modern workflows.

Flexible Control Options

The CV620 offers easy control over iris, shutter, white balance, focus, pan/tilt speeds, and more, controllable by IR remote, RS-232, or RS-422 with support for control protocols including Visca, Pelco, and more.

Additionally, the CV620 is compatible with Marshall's VS-PTC-IP PTZ Camera Controller, providing intuitive adjustment of pan/tilt/zoom, pan/tilt speeds, white balance, and more with one button dials and rocker control.
