xMac Studio/Echo III

Professional 3U Rackmount Enclosure with Three Slot Thunderbolt to PCIe Card Expansion System for Mac Studio

Designed for Three PCIe Cards Expansion - Connect Speciality Audio and Video Cards

For many creative professionals, PCIe card expansion is not an option - its a necessity for connecting specialty cards to handle audio and video post-production projects. xMac Studio is a rugged steel 3U rackmount enclosure for securing a Mac Studio with optional PCIe card expansion module in a rack, placing the Mac Studio behind a quick and easy to remove front panel. Sonnet designed the xMac Studio/Echo III for pro workflow flexibility; a rugged steel enclosure protects the Mac Studio while a three slot PCIe expansion module provides expansion for up to three PCI cards, including support for up to three Avid Pro Tools | HDX cards.

Echo III Expansion Module Features

Versatile PCIe Card Expansion - From low-profile, half-length to full-height, full-length in size, Echo expansion modules support every Thunderbolt-compatible, non-GPU PCIe card available. View PDF of supported PCIe cards.

400W of Power - Built-in 400W power supply supports power-hungry cards including Avid Pro Tools | HDX, AJA® Kona® 5, Blackmagic Decklink 4K Extreme 12G, and Blufish444's Epoch and KRONOS SDI cards. System powers on and off automatically with the connected Mac Studio.

Quiet Fans - Dual temperature-controlled, variable-speed Noctua fans rated at 17 dbA offer ultra-quiet operation.

40Gbps Thunderbolt Interface - 40Gbps Thunderbolt interface offers 2800 MB/s of PCIe bandwidth to the installed PCIe cards.

Control and Connect - Easy Access to Mac Studio and PCIe Card Expansion Module

Convenient front panel operation allows you turn Mac Studio on with its own dedicated front power button, connect USB devices through a 4-port USB-A hub, and access the computer's front ports and SD card slots. When equipped with an Echo III or Echo I PCIe Card Expansion Module, three rear panel locking thumbscrews allow you to easily pull out and access the module and PCIe cards through the front without removing the front panel. xMac Studio's design enables you to connect and disconnect cables without needing to remove the Mac Studio from the enclosure.

An opening on top of xMac Studio ensures hindrance-free wireless signal access. The xMac Studio is designed to allow normal WiFi and Bluetooth wireless operation in most configurations (depending on rack type and position in rack), so you can use wireless devices and iOS® device control apps.

Mac Studio computer and PCIe cards not included

RackMac Studio

3U Pro Rackmount Enclosure to Install and Secure One or Two Mac Studio Computers in a Standard 19-inch Rack

Control and Connect - Easy Access to Mac Studio Computers

RackMac Studio is a rugged steel 3U rackmount enclosure for securing one or two Mac Studio computers in a rack, placing them behind a quick and easy to remove front panel. Convenient front panel operation allows you turn Mac Studio computers on with their own dedicated front power buttons, connect USB devices through passthrough USB-A ports, and access the computers' front ports and SD card slots. RackMac Studio's design enables you to connect and disconnect cables easily without needing to remove the computers from the enclosure.

Openings on top of RackMac Studio ensure hindrance-free wireless signal access. The RackMac Studio is designed to allow normal WiFi and Bluetooth wireless operation in most configurations (depending on rack type and position in rack), so you can use wireless devices and iOS® device control apps.

Go with the Airflow - Supports Mac Studio's Thermal Design

RackMac Studio secures your Mac Studios without trapping them in recirculating hot rack air, supporting their thermal design to keep them as cool in a rack as out on a desk. Ventilation holes on the enclosure's front panel plus an enclosed chamber beneath each computer ensure the computers' ability to draw in cool air through their bases, while a completely open back enables them to expel warm air out the back unimpeded.

Space for SSD Drives - Secure up to Three Thunderbolt or USB SSD Drives Under Each Mac Studio Computer

RackMac Studio provides space beneath each Mac Studio computer to house up to three Thunderbolt or USB SSDs (sold separately) up to 3.2 inches wide by 0.75 inch tall. Simply remove the rear access panel, apply the supplied adhesive-backed magnet to the bottom of the SSD, insert the SSD and connect it to the computer, and then reinstall the panel. The space is also suitable for other thin, bus-powered devices.

Road Trip Ready - Workflows on the Go

Do you need to take your workflow on the road? The RackMac Studio is a perfect travel solution. Its 9.5-inch mounting depth - plus firm rubber cushions that securely hold your Mac Studios in place during transport - make RackMac Studio ideal for use in shallow molded rack cases from Gator Cases, fly racks from SKB Cases, or most any travel rack.

xMac Studio

Professional 3U Rackmount Enclosure with Optional Thunderbolt to PCIe Card Expansion System for Mac Studio

Designed for Mac Studio with Expansion Bay to Connect Speciality Audio and Video Cards

For many creative professionals, PCIe card expansion is not an option - its a necessity for connecting specialty cards to handle audio and video post-production projects. xMac Studio is a rugged steel 3U rackmount enclosure for securing a Mac Studio with optional PCIe card expansion module in a rack, placing the Mac Studio behind a quick and easy to remove front panel. Sonnet designed the xMac Studio for pro workflow flexibility; a rugged steel enclosure protects the Mac Studio while an expansion bay provides the option for a Sonnet Echo III or Echo I PCIe Card Expansion Module.

Control and Connect - Easy Access to Mac Studio and Optional PCIe Card Expansion Module

Convenient front panel operation allows you turn Mac Studio on with its own dedicated front power button, connect USB devices through a 4-port USB-A hub, and access the computer's front ports and SD card slots. When equipped with an Echo III or Echo I PCIe Card Expansion Module, three rear panel locking thumbscrews allow you to easily pull out and access the module and PCIe cards through the front without removing the front panel. xMac Studio's design enables you to connect and disconnect cables without needing to remove the Mac Studio from the enclosure.

An opening on top of xMac Studio ensures hindrance-free wireless signal access. The xMac Studio is designed to allow normal WiFi and Bluetooth wireless operation in most configurations (depending on rack type and position in rack), so you can use wireless devices and iOS® device control apps.

Go with the Airflow - Supports Mac Studio's Thermal Design

xMac Studio secures your Mac Studio without trapping in recirculating hot rack air, supporting its thermal design to keep it as cool in a rack as out on a desk. Ventilation holes on the enclosure's front panel plus an enclosed chamber beneath the Mac Studio ensures the computer's ability to draw in cool air through its base, while a completely open back enables it to expel warm air out the back unimpeded.

Space for SSD Drives - Secure up to Three Thunderbolt or USB SSD Drives Under the Mac Studio

xMac Studio provides space beneath the computer to house up to three Thunderbolt or USB SSDs (sold separately) up to 3.2 inches wide by 0.75 inch tall. Simply remove the rear access panel, apply the supplied adhesive-backed magnet to the bottom of the SSD, insert the SSD and connect it to the computer, and then reinstall the panel. The space is also suitable for other thin, bus-powered devices.

Road Trip Ready - Workflows on the Go

Do you need to take your workflow on the road? The xMac Studio is a perfect travel solution. Its 16.5-inch mounting depth - plus firm rubber cushions that securely hold your Mac Studio in place during transport - make xMac Studio ideal for use in molded rack cases from Gator Cases, fly racks from SKB Cases, or most any travel rack.

Benefit From a Secure Connection

Thunderbolt connectors are held in place by friction. While that works well in situations where equipment remains undisturbed while operating, when there's a chance of movement nearby, there's a chance the Thunderbolt cable can be unintentionally unplugged, possibly leading to loss of your work or data. To solve this problem, Sonnet designed the ThunderLok, a Thunderbolt connector retainer clip, to prevent accidental cable disconnections from many of Sonnet's current Thunderbolt products. It is easy to install and use-just slide it over one end of the cable, and then plug in the connector and secure it to the product by turning a thumbscrew. Because of its unique design, ThunderLok does not attach to the connector, but remains on the cable so it won't get lost when not in use. Sonnet already includes a single ThunderLok with many of its Thunderbolt products. Buy additional ThunderLoks to secure a downstream device's cable! Works with all known copper Thunderbolt cables. Does not work with optical Thunderbolt cables.

Ingest P2 Content, Fast

Sonnet's Thunderbolt Pro P2 Card Reader quickly transfers files from Panasonic P2 memory cards to your Mac (with Thunderbolt or Thunderbolt 2 ports) on location, in the studio, or in the edit suite. This single-slot reader's ability to transfer data from P2 cards at much higher speeds than USB 2.0 card readers are capable makes for a significantly more convenient and efficient workflow. Its value price makes it the most cost-effective P2 card reader available.

The Thunderbolt Pro P2 Card Reader can ingest files from P2 memory cards up to four times as fast as other single-slot card readers. Requiring only a single cable to connect to your Mac, this high-performance Sonnet reader is bus powered (no separate power supply required) and exploits its 10Gbps Thunderbolt interface to deliver superior performance. As a result, this memory card reader transfers data at up to 600 mb/s!

The Thunderbolt Pro P2 Card Reader connects directly to your Mac's Thunderbolt port or at the end of a Thunderbolt device chain. The reader supports all P2 memory cards and frame rates, and supports microP2 cards with an adapter (sold separately).

Measuring a compact 3.6 inches wide by 1 in high by 4.5 inches deep, the Thunderbolt Pro P2 Card Reader is the smallest P2 reader available, making it perfect for use anywhere space is tight. The reader's shell is made from extruded aluminum, making it lightweight, and yet rugged enough to be transported in an equipment bag without fear of cracking the case. Sonnet includes a Thunderbolt cable for directly connecting the card reader your system.

• Extra Quiet Fan Module-Suitable for use with most PCIe cards; offers the lowest noise possible
• Easy Installation-User installable
• Compatibility-Compatible with all xMac mini Server models

Extra Quiet Option for Your xMac mini Server

If the quietest operating xMac mini Server your ultimate goal, the xMac mini Server Quiet Fan Module will help you achieve it. Easy to install, this module replaces the standard fan module in your xMac mini Server, and is suitable for use with cool-running PCIe cards, including most pro audio, video capture & processing, and many other cards. Because this module's fans spin more slowly and move less air than the standard fan module, this option is not recommended for use with SAS host bus adapters and RAID controllers, Fibre Channel, or 10 Gigabit Ethernet cards.

DuoModo xMac mini/Echo III Rackmount System | Mac mini Integration + Three PCIe Slots

The pre-configured DuoModo™ xMac™ mini/Echo™ III Rackmount System integrates a Dual-Module Rackmount Enclosure with one xMac mini module and one Echo III module.

Connect Two 4K DisplayPort Displays Using Only One Port on Your M1 Mac

DisplayLink Dual DisplayPort Adapter for M1 Macs and Other Mac and Windows Computers

Two DisplayPort Displays from a Single USB or Thunderbolt Port

Apple® M1 Mac® computers offer outstanding overall performance but have a limit to the number of external displays you can connect to them. If you're using an M1 MacBook Air® or MacBook Pro®, that number is one. Featuring DisplayLink technology, Sonnet's DisplayLink™ Dual DisplayPort Adapter for M1 Macs beats the limit, enabling you to connect two 4K @ 60Hz or two 1440p @ 144Hz DisplayPort displays to a single port on your computer.

Efficiency Booster | Expand Your Applications Workspace

Perfect for use with productivity software such as Microsoft® Office, this Sonnet adapter enables you to work more efficiently by expanding your workspace. Whether you need to open multiple applications on their own screens, edit code or view a spreadsheet in detail on a large display, or mirror your notebook's display on a larger monitor, the Sonnet DisplayLink Dual DisplayPort Adapter for M1 Macs makes it possible.

Go Full Screen | Browse the Web. Watch Videos.

Even when you're not using productivity software, your notebook's screen can constrain your view. Go big-the Sonnet DisplayLink Dual DisplayPort Adapter for M1 Macs enables you to connect your computer to your large monitor or big screen TV to browse the web and watch videos on YouTube and other content at a distance.

Long-range USB Bluetooth 4.0 Micro Adapter | Enhances Bluetooth Performance of xMac mini Server, RackMac mini, DuoModo xMac mini Module, and Mac and Windows computers

For any Mac mini® user who mounted their computer in one of Sonnet's Mac mini rackmount solutions, improving your computer's Bluetooth® performance is simple-plug in a Sonnet Long-Range USB Bluetooth 4.0 Micro Adapter. Connected to the front panel USB port, this adapter moves your Bluetooth connection to outside the enclosure, enabling better performance with mice, keyboards, headsets, speakers, printers, phone, tablet, and other Bluetooth devices.

Key Features

• Extends Bluetooth Range for Sonnet's Mac mini RackMount Solutions
• Broad Device Support
• macOS and Windows Compatible -
  Supported in Macs running macOS 10.12+ and in Computers Running Windows 11 or 10
• Supports Wireless Music Streaming
• Micro-size Adapter
• Extended Transmission Range - Up to 50 Meters (165 Feet) Range
• Supports Seven Devices Simultaneously
• Enhanced Data Rate (EDR) Support
• Bluetooth Low Energy (BLE) Support
• 2-year Product Warranty
• Free Lifetime Customer Technical Support

Strong Signal. Small Size.

Sonnet's Long-Range USB Bluetooth 4.0 Micro Adapter is so small that it almost disappears when you plug it in. Because of its tiny size, you can safely leave it plugged into your computer or Sonnet Mac mini rackmount solution during transport. Despite its size, the adapter can support receive and send ranges of up to 50 meters (165 feet), allowing greater flexibility in connecting your devices.

Supports Up to Seven Devices Simultaneously at Up to 3Mbps

Sonnet's Long-Range USB Bluetooth 4.0 Micro Adapter is so small that it almost disappears when you plug it in. Because of its tiny size, you can safely leave it plugged into your computer or Sonnet Mac mini rackmount solution during transport. Despite its size, the adapter can support receive and send ranges of up to 50 meters (165 feet), allowing greater flexibility in connecting your devices.

SSDs (solid state drives) offer fantastic data storage read/write speeds, in some cases delivering performance many times faster than hard disk drives are capable. But, if you want to install them in your desktop computer or multi-drive storage system, you can't use them out of the box like standard hard drives-the problem is they're too small. Sonnet's Transposer is the solution you need-it adapts any 2.5" form factor SSD (or hard drive) to any 3.5" form factor drive tray, without cables or hassles. Now you can add SSDs to your system effortlessly!

10 Gigabit Wired Networking

Ultra-Fast 10 Gb/s Network Connection

With creative pros' increasing demand for greater data transfer speeds and more bandwidth over shared networks, it's no wonder that 10 Gigabit Ethernet (10GbE) use has skyrocketed-this high-speed wired networking standard offers ten times the performance of Gigabit Ethernet, the common wired network connection included with most computers today. To get your computer up to speed, you'll have to adapt-Sonnet's Presto™ 10GbE 10GBase-T PCIe 3.0 card is a powerfully simple and cost-effective way to add dual-port copper 10GbE connectivity to your Mac Pro® tower or Windows® PC.

Step Up to 40Gbps Thunderbolt 3

Sonnet designed Echo Express Thunderbolt 2-to-PCIe card expansion systems (and select Thunderbolt 2 adapters) to be easily upgraded to 40Gbps Thunderbolt 3. Simply replace the existing Thunderbolt interface board with the upgrade board, and then your chassis will instantly support higher performance, and connect to your Thunderbolt 3-equipped computer without needing an adapter.

Increased Bandwidth, Better Performance

With a Thunderbolt 3 interface card installed, your upgraded Echo Express Thunderbolt 2 system gains from 30% to 100% more bandwidth over the original system (see performance Tab for details). Installed in an upgraded system, PCIe cards with high bandwidth requirements, such as 16Gb Fibre Channel and 4K Video I/O cards supporting high frame rates, will be able to perform even better than before.

Step Up to 40Gbps Thunderbolt 3
Sonnet designed Echo Express Thunderbolt 2-to-PCIe card expansion systems (and select Thunderbolt 2 adapters) to be easily upgraded to 40Gbps Thunderbolt 3. Simply replace the existing Thunderbolt interface board with the upgrade board, and then your chassis will instantly support higher performance, and connect to your Thunderbolt 3-equipped computer⁽²⁾ without needing an adapter.

Increased Bandwidth, Better Performance

With a Thunderbolt 3 interface card installed, your upgraded Echo Express Thunderbolt 2 system gains from 30% to 100% more bandwidth over the original system (see performance Tab for details). Installed in an upgraded system, PCIe cards with high bandwidth requirements, such as 16Gb Fibre Channel and 4K Video I/O cards supporting high frame rates, will be able to perform even better than before.
