Another Step Forward in Energy Efficiency and TCO
Building on the tremendous success of their predecessors, the new AMD EPYC 8004 Series processors continue to push AMD's 5nm "Zen 4c" architecture with a focus on greater energy efficiency and cost optimized. The new 8004 series achieves higher performance/watt and performance/$ and of this is achieved while retaining the features of mainstream general-purpose processors, including PCIe 5.0 and DDR5 memory with ECC support. The AMD EPYC 8004 Series processors are best suited for cloud service providers, edge/telco, storage, and SMB.
4th Gen AMD EPYC Processors for SP6 Socket | 5nm architecture
Compute density increased with more transistors packed in less space
Zen 4c cores
Rearranged CPU design creates even higher core density at 5nm
SP6 compatibility
The new socket lowers BOM cost while keeping future upgrade potential
DDR5 memory
Increased memory throughput and higher DDR5 capacity
PCIe 5.0 lanes
Increased I/O throughput achieving 128GB/s bandwidth
CXL 1.1+ support
Disaggregated compute architecture possible via Compute Express Link
LowTDP
Lowest TDP in the EPYC portfolio with improved perf/W and perf/$
SFFdesign
Smaller form factor enables shallow depth and small-footprint server designs
Select GIGABYTE for the AMD EPYC 8004 Platform | High Performance
Servers and motherboards by GIGABYTE are tested to ensure peak performance for demanding CPU workloads. All the latest technology is supported.
Fast & Stable Connectivity
Keeping pace with the challenges for next gen technology, well designed GIGABYTE boards provide users the signal integrity for PCIe 5.0.
Modularity
Our building block design allows new models to quickly come to market. And users can now have BMC on a OCP module customized by GIGABYTE.
Optimal Price
Our broad portfolio of products allows customers to only select the features they require while doing so at a lower TCO.
Continuous Operation
Systems are rigorously designed and tested to ensure downtime will not occur. Customers have come to expect stable performance around the clock.
Energy Efficiency
Our engineers have baked in features to achieve higher efficiency by customizing fan curves and by the choice of PSU -Titanium or Platinum.
Edge / Telecom Application Focus Server
In response to the gradual integration of 5G into modern life and the increasing utilization of edge computing for localized data processing, GIGABYTE offers servers with a short depth and compact form factor. These servers are designed to fit into various facilities while ensuring system stability and security, all aiming toward a low Total Cost of Ownership (TCO). This comprehensive range guarantees a perfect fit for every use case, addressing the need for affordable, easily adoptable, and maintainable solutions that can function effectively even in non-traditional data center environments.
Power Efficiency | Automatic Fan Speed Control
GIGABYTE servers are enabled with Automatic Fan Speed Control to achieve the best cooling and power efficiency. Individual fan speeds will be automatically adjusted according to temperature sensors strategically placed in the servers.
General Information | |
Manufacturer | GIGABYTE Technology, Inc |
Manufacturer Part Number | R243EG0AAL1 |
Manufacturer Website Address | http://www.gigabyte.us |
Brand Name | Gigabyte |
Product Model | R243-EG0 |
Product Name | R243-EG0 (rev. AAL1) Barebone System |
Packaged Quantity | 1 |
Product Type | Barebone System |
Processor | |
Number of Processors Supported | 1 |
Processor Socket | Socket SP6 LGA-4844 |
Processor Supported | EPYC |
Chipset | |
Chipset Manufacturer | AMD |
Memory | |
Maximum Memory Supported | 96 GB |
Memory Technology | DDR5 SDRAM |
Memory Standard | DDR5-4800/PC5-38400 |
Number of Total Memory Slots | 12 |
Controllers | |
Controller Type | Serial Attached SCSI (SAS) |
Controller Type | Serial ATA |
RAID Supported | No |
Display & Graphics | |
Graphics Controller Manufacturer | ASPEED |
Graphics Controller Model | AST2600 |
Graphics Memory Technology | DDR4 SDRAM |
Network & Communication | |
Ethernet Technology | Gigabit Ethernet |
I/O Expansions | |
Number of Total Expansion Bays | 12 |
Number of 3.5" Bays | 12 |
Number of Total Expansion Slots | 5 |
Number of PCI Express x16 Slots | 4 |
Number of M.2 Interfaces | 2 |
Interfaces/Ports | |
Total Number of USB Ports | 4 |
Number of USB 3.2 Gen 1 Ports | 4 |
Network (RJ-45) | Yes |
Mini DisplayPort | Yes |
Power Description | |
Input Voltage | 230 V AC |
Input Voltage | 120 V AC |
Plug/Connector Type | C19 |
Number of Power Supplies Installed | 2 |
Maximum Power Supply Wattage | 2700 W |
Physical Characteristics | |
Form Factor | Rack-mountable |
Rack Height | 2U |
Height | 3.4" |
Width | 17.2" |
Depth | 32.1" |
Miscellaneous | |
Package Contents |
|
Environmentally Friendly | Yes |
Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Warranty | |
Limited Warranty | 3 Year |
Additional Warranty Information | A warranty of 3 years is offered as standard for GIGABYTE server motherboards, server barebone systems & embedded solutions. |
